System battery

PBA 18V 2.5Ah W-B

Unit Value (Art. 14903)

Battery voltage V (DC) 18

Battery capacity Ah 2.5

Number of cells (Li-Ion) 5

Suitable POWER FOR ALL

system battery chargers

AL 1810 CV/AL 1815 CV/AL 18V-20/

AL 1830 CV/AL 1880 CV

Battery charger

AL 1810 CV P4A

Unit Value (Art. 14900)

Mains voltage V (AC) 220–240

Mains frequency Hz 50–60

Rated current W 26

Battery charging voltage V (DC) 18

Max. battery charging current mA 1000

Battery charging time (approx.)

PBA 18V 2.0Ah W-B

PBA 18V 2.5 Ah W-B

PBA 18V 4.0 Ah W-C

min.

115

136

228

Permissible charging

temperature range

°C 0–35

Weight according to EPTA

procedure 01:2014

kg 0.17

Protection class

/ II

Suitable POWER FOR ALL

system batteries

PBA 18V

8. ACCESSORIES/SPARE PARTS

GARDENA Roller Brush

Universal

As a replacement for a worn roller brush, e.g.

for wooden surfaces.

Art. 14848

GARDENA Roller Brush

Medium

As a replacement for a worn roller brush, e.g.

for stone surfaces.

Art. 14849

GARDENA Disc Brush Soft As a replacement for a worn disc brush. Art. 14847

GARDENA Disc Brush Unit As a supplement to the multi-cleaner for other

possible uses.

Art. 14846

GARDENA Extension Handle For extending the GARDENA Cordless Multi-

Cleaner Art. 14840.

Art. 14845

GARDENA System Battery

P4A PBA 18V/45

P4A PBA 18V/72

Battery for additional run time or for

replacement.

Art. 14903

Art. 14905

GARDENA Battery Quick

Charger AL 1830 CV P4A

For fast charging of the POWER FOR ALL

system batteries PBA 18V..W-..

Art. 14901

9. SERVICE/WARRANTY

9.1 Product registration

Please register your product at gardena.com/registration.

9.2 Service

Pleasendthecurrentcontactinformationofourserviceonthebackpage

and online:

• United Kingdom: https://www.gardena.com/uk/support/advice/

contact/

• Australia: https://www.gardena.com/au/support/advice/contact/

• New Zealand: https://www.gardena.com/nz/support/advice/contact/

• South Africa: https://www.gardena.com/za/support/contact/

10. DISPOSAL

10.1 Disposal of the multi-cleaner

(in accordance with Directive 2012/19/EU/S.I. 2013 No. 3113)

The product must not be disposed of with normal household

waste. It must be disposed of in accordance with the applicable

local environmental regulations.

Problem Possible cause Remedy

Brush is blocked Obstacle is blocking the brush.

v Remove the obstruction.

The multi-cleaner does not

clean properly or vibrates

Brush is worn.

v Replace the brush.

The multi-cleaner

does not stop

Start lever is jammed.

v Remove the battery and

loosen the start lever.

The multi-cleaner

does not start or stops.

LED

flashes green

[Fig. O4]

Battery is at.

v Charge the battery.

The multi-cleaner

does not start or stops.

Error-LED

lights up red

[Fig. O4]

Battery temperature is outside

the permissible range.

v Wait until the battery tem-

perature is between 0°C and

+ 45°C again.

There are drops of water or

moisture between the battery

contacts.

v Remove the water drops or

moisture with a dry cloth.

Obstacle is blocking the motor.

v Remove the obstruction.

The multi-cleaner

does not start or stops.

Error-LED

flashes red

[Fig. O4]

The multi-cleaner is defective.

v Contact GARDENA Service.

The multi-cleaner

does not start or stops.

Error-LED

does not light

up [Fig. O4]

Battery is not fully inserted into

the battery holder.

v Insert the battery completely

into the battery holder until it

audibly engages.

The battery is defective.

v Replace the battery.

The multi-cleaner is defective.

v Contact GARDENA Service.

The charge cycle

is not possible.

Battery charge indicator

lights up green continuously

The battery is not pushed onto

the battery charger correctly.

v Push the battery onto the bat-

tery charger correctly.

Battery contacts are dirty.

v Clean the battery contacts

(e. g. by connecting and dis-

connecting the battery sever-

al times. Replace the battery

if necessary).

Battery temperature is outside

the permissible range.

v Wait until the battery temper-

ature is between 0°C and

+45°C again.

The battery is defective. v Replace the battery.

The charge cycle

is not possible.

The battery charge

indicator

is not lit

The mains plug of the battery

charger is not plugged in cor-

rectly.

v Insert the mains plug com-

pletely into the power outlet.

The power outlet, mains cable

or battery charger is defective.

v Check the mains voltage. If

necessary, have the battery

charger checked by an

authorised dealer or by

GARDENA Service.

NOTE:

Repairs may only be carried out by GARDENA service centres or by

specialist dealers approved by GARDENA.

v Please contact your GARDENA service centre in the event of other faults.

7. SPECIFICATION

Multi-cleaner

Unit Value

(Art. 14840)

Value

(Art. 14841)

Value

(Art. 14842)

Roller brush speed

(min/max)

rpm 350–1000 350–1000

Disc brush speed

(min/max)

rpm 350–1000 350–1000

Roller brush width cm 10 10

Disc brush diameter cm 17 17

Max. water flow rate l/h 100 100 100

Weight (excluding battery) kg 2.7 4.0 3.2–4.0

GAR_14840-20.960.03.indd 13GAR_14840-20.960.03.indd 13 07.02.2024 09:13:4507.02.2024 09:13:45
