FURUNO
VR-7000/7000S
SP - 4 E4495S01L-M
241224
Number of channels for picture recording
Device
Video LAN converter
IEC61162-450 PNG
IEC61162-450 JPEG
Quality ≥ 50 Quality < 50
Fixed/ float-free DRU or
long term device (single)
UXGA: 2ch + full-HD: 1ch,
Total 3ch
3ch 5ch
Long term device (dual) UXGA: 2ch + full-HD: 1ch
+ WUXGA: 1ch, Total 4ch
4ch 6ch
Picture recording pattern Selectable for each channel (Only one/Patrol/Backup)
8 POWER SUPPLY
8.1 Data collecting unit 100-230 VAC: 1.6-0.7 A, 1 phase, 50/60 Hz
8.2 Sensor adapters (option) 24 VDC: 1.4 A max. (11 units), fed from DCU
8.3 Video LAN converter (IF-7100, option) 24 VDC: 0.3 A (SER.NO. 100000 to 199999: 0.7 A)
8.4 HUB (option)
HUB-3000 100-230 VAC: 0.1 A, 1 phase, 50-60 Hz
HUB-100 100-230 VAC: 0.1 A, 1 phase, 50-60 Hz
9 ENVIRONMENTAL CONDITIONS
9.1 Ambient temperature
Data collecting unit -15°C to +55°C
Fixed DRU -25°C to +55°C
Float-free DRU -20°C to +55°C
Waterproof microphone -25°C to +55°C
Others -15°C to +55°C
9.2 Relative humidity 93% or less at +40°C
9.3 Degree of protection
Data collecting unit IP20
Fixed DRU IP56 equivalent (VR-7020), IP66 (VR-7023)
Float-free DRU IP67 equivalent
Remote alarm panel IP22 (front panel), IP20 (chassis)
Sensor adapter IP20 (IP22: option)
Junction box IP20 (IF-8540), IP56 (VR-7022F)
Video LAN converter IP20 (IP22: for bulkhead mount)
Microphone IP22 (panel), IP20 (chassis)
Waterproof microphone IP56
HUB-3000 IP20 (IP22: option)
HUB-100 IPX0
9.4 Vibration IEC 60945 Ed.4
10 UNIT COLOR
10.1 Data collecting unit N2.5 (standard)
10.2 Fixed DRU Fluorescent orange (fixed)
10.3 Float-free DRU Fluorescent orange (chassis), White (bracket)
10.4 Remote alarm panel/ Video LAN converter/ Sensor adapter
N2.5
10.5 Junction box N2.5 (IF-8540), 7.5BG7/2 (VR-7022F)
10.6 Microphone/ Waterproof microphone N2.5 (fixed)
10.7 HUB N2.5 (HUB-3000), N3.0 (HUB-100)
