2. MAINTENANCE
2-16
Buzzer test
1. Open the test menu.
2. Use the cursorpad ( or ) to select [Buzzer Test] then press the ENT key. The
buzzer test window appears then a buzzer sounds for 60 seconds.
Note 1: The buzzer test window closes automatically when there is no menu op-
eration for 60 seconds.
Note 2: You can cancel the test at any time by pressing any key.
2.7 Verification of Recording Function of the Long
Term Device
Verify the long term device recording function at the annual inspection and when re-
pairing or maintaining the VDR or sensors connected to the VDR. The verification re-
quires the Live Player V5. Refer to its Operator's Manual for the operating procedure.
1. Start the Live Player V5 on the PC.
2. Connect the LAN cable between J502 port on the DCU and the PC.
3. Open the [Tool] menu and select [Source Select].
4. Select [Long Term Device (LAN)] from the menu.
5. Click the [Analyze Track] button.
6. Click the [Connect] button.
7. Select [Extract] from the [Tool] menu to show the [Extraction] dialog box.
8. Activate the [Track Selection] radio button, then check the track you want to ex-
tract.
9. Click the [Select] button and select the location where to save data.
10. Click the [Start] button.
11. After the extraction* is completed, click [OK], [Close] and [Close] in that order.
Then, disconnect the cable between the PC and J502 in the DCU.
*: The time required for the extraction depends on the VDR environment and
specifications of the PC to be extracted. See the table below.
Amount of extraction data Time required for extraction File size on the PC
1 hour 1 to 2.5 minutes 300 to 900 MB
12 hours 15 to 22 minutes 3.5 to 8 GB
Buzzer Test
A buzzer is sounded for 60 seconds.
DATA
port J502
PC
LAN cable
DCU
