1. OPERATION
1-9
[Sensor(LAN) Monitor]
You can monitor the sensor information input to the LAN channels.
To see the information for a sensor(LAN) channel, use the cursorpad to select a sen-
sor(LAN) channel (LN01 to LN64) then press the ENT key to show the sensor (LAN)
monitor screen. The latest received data is displayed on the top of the screen.
Press the ENT key to stop the sensor display. To restart the sensor display, press the
ENT key again.
[Analog Monitor]
You can monitor the sensor information input to the analog channels (AN001 to
AN120).
To shift the page,
use the cursorpad
(◄ or ►).
Sensor
(
LAN
)
Channel Select
◄
1
(
LN01 - LN30
)
►
LN11:XXXXX
LN12:XXXXX
LN13:XXXXX
LN14:XXXXX
LN15:XXXXX
LN16:XXXXX
LN17:XXXXX
LN18:XXXXX
LN19:XXXXX
LN20:XXXXX
LN21:XXXXX
LN22:XXXXX
LN23:XXXXX
LN24:XXXXX
LN25:XXXXX
LN26:XXXXX
LN27:XXXXX
LN28:XXXXX
LN29:XXXXX
LN30:XXXXX
LN01:GPS
LN02:XXXXX
LN03:XXXXX
LN04:XXXXX
LN05:XXXXX
LN06:XXXXX
LN07:XXXXX
LN08:XXXXX
LN09:XXXXX
LN10:XXXXX
[
MENU
/
ESC
]
:
Back
[
ENT
]
:
In
p
ut
▲
/
▼
/
◄
/
►
:
Select
To switch the channel,
use the cursorpad
(◄ or ►).
Sensor
(
LAN
)
Monitor
◄
LN01
►
$GPZDA.104523.4582.23.12.2012.09.00•54
$GPGNS.104523.477.3434.000.N.13510222.E.N.01.1.1.5.0.-2.3.4.1.0•3A
$GPDTM.W84.0.0.1.N.1.0.W.2.0.W72•46
$GPVTG.176.T.180.0.M.1.0.N.1.8.K.A•3C
[
MENU
/
ESC
]
:
Back
[
ENT
]
:
Sto
p
◄
/
►
:
Select
To switch the channel,
use the cursorpad
(◄ or ►).
Analo
g
Monitor
◄
1
(
AN001 - AN016
)
►
AN001: - 0. 04V
AN002: 1. 23mA
AN003: 0. 50V
AN004: - 1. 00V
AN005: 0. 23mA
AN006: - 1. 11V
AN007: 0. 45mA
AN008: 2. 50V
AN009: - 2. 12V
AN010: 3. 48V
AN011: 2. 10V
AN012: - 0. 90V
AN013: 6. 17mA
AN014: 4. 39mA
AN015: 2. 25V
AN016: 1. 04V
[
MENU
/
ESC
]
:
Back
◄
/
►
:
Select
