1. OPERATION
1-4
ship’s mark and position (latitude and longitude), course, speed, voyage plan, and oth-
er essential navigational indications are included in the recorded ECDIS image. One
complete picture frame is captured at intervals of 15 s. Scanning may be interlaced or
non-interlaced.
The channel number and resolution can be recorded is shown in the table below.
*: Recorded to the long term device (SSD) only. Not recorded to the Fixed DRU and
Float-free DRU.
Bridge audio: Up to eight microphones are supplied as standard to record conversa-
tion at conning station, radar display and chart table. Microphone captures conversa-
tion in the bridge, audio signals from equipment and sound from machinery. The
microphone generates a test beep every 12 hours which is also recorded. The micro-
phone picks up audio signals ranging from 150 to 6000 Hz.
Communications audio: A maximum of two VHF communications are recorded for
both transmitted and received audio signals.
Minimum data retention period
The VDR data is retained in the recording media, following termination of recording.
The minimum data retention periods for each recording unit are shown in the table be-
low (IEC61996-1/IEC61996-2 compliant).
Input method No. of pcs Resolution/Max. channel number
Inputs through
the video LAN
converter
1 SSD
(512 GB)
UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch
2 SSDs
(1 TB)
UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch +
WUXGA (1920×1200): 1 ch*
IEC61162-450
format
1 SSD
(512GB)
For PNG format:
UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch
For JPEG format (quality is 50 or above):
WUXGA (1920×1200): 3 ch
For JPEG format (quality is less than 50):
WUXGA (1920×1200): 5 ch
2 SSDs
(1TB)
For PNG format:
UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch +
WUXGA (1920×1200): 1 ch*
For JPEG format (quality is 50 or above):
WUXGA (1920×1200): 3 ch + WUXGA (1920×1200): 1 ch*
For JPEG format (quality is less than 50):
WUXGA (1920×1200): 5 ch + WUXGA (1920×1200): 1 ch*
Unit Minimum Data Retention Period
Long term device (DCU)
2 years after recording
Fixed DRU
Float-free DRU 6 months after recording
