1. OPERATION
1-2
Data Collecting Unit
The DCU mainly consists of a Data Processor Unit and Power Control Panel. The
DCU includes batteries with a lifetime of approximately four years. The DCU collects
the data from various sensors radar/ECDIS and records them in the Fixed DRU, Float-
free DRU and internal long term device.
Recording interval of data and audio is as follows:
• Radar/ECDIS video signal: every 15 seconds
• Bridge and VHF audio: real time
• IEC sentences: when received
• Analog and digital data: every second
For VR-7000, you can select one or two 512-GB SSD(s) as internal long term de-
vice(s). When selecting one SSD, you can add another one using an optional SSD kit
later.
*: The recording interval for 3 channels is 15 seconds, which is compliant with
IEC61996-1 Ed.2.1 and IEC61996-2 Ed.2.0. Other channels record a maximum of
four video signals at intervals of 15 seconds, using the time-division method.
For VR-7000S, there are four save areas (Area1, 2, 3, 4) in the long term device(s).
Each area can record data for 12 hours.
Data Recording Unit
Fixed DRU
The Fixed DRU is housed in a highly visible protective capsule which can withstand a
fire of 1,100°C for one hour and deep-sea pressure of 6,000 m.
The underwater acoustic beacon (pinger) on the capsule automatically transmits 10
ms pulses at 37.5 kHz for at least 90 days when it is submerged in water. The expect-
ed life of the beacon battery is three years.
Float-free DRU
The capsule of the Float-free DRU has the same functionality of an satellite EPIRB
(Emergency Position-Indicating Radio Beacon). The VDR data is recorded in the stor-
age module at the bottom of capsule.
The DCU feeds the VDR data to the bracket of the Float-free DRU through the LAN
cable, then the bracket feeds the data to the capsule by wireless communication.
The capsule of the Float-free DRU is stored in the bracket. When the Float-free DRU
sinks to depths of up to four meters, the capsule is automatically released from the
bracket then floats to the sea surface. At the same time, the capsule starts to transmit
406 MHz signal for locating the position of capsule, 121.5 MHz signal for homing and
AIS messages (VR-7024F only) for at least 168 hours.
Note: Select fixed DRU or float-free DRU for VR-7000S.
No. of pcs Storage time Video signal channels recorded at the same time
1 SSD (512 GB) 720 hours Up to 5 channels*
2 SSDs (1 TB) Up to 6 channels*
