Gain
NoteNoteNoteNoteNote
[TX/STBY] toggles between TX and standby.
66
Fish Finder
How to show past echoes (echo history)
Swipe leftward or rightward
to show past echoes.
Return to normal display.
Note 1: Names of menu items may be different depending on the transducer connected on the network.
Note 2: TZT10X/13X/16X: Compatible with built-in or network fish finders.
TZT22X/24X/BBX: Compatible with network fish finders.
Note 1: Names of menu items may be different depending on the transducer connected on the network.
Note 2: TZT10X/13X/16X: Compatible with built-in or network fish finders.
TZT22X/24X/BBX: Compatible with network fish finders.
How to select a frequencyHow to select a frequency
(HF: High Freq.)
Single Freq.
Dual Freq.
Low frequency: For “normal” use.
High (Middle) frequency: For detailed observation of schools of fish.
Dual frequency: Show both the low and high frequency pictures.
Tap
Tap
Tap
Open the Layers menu;
tap the [Fish Finder] tab.
(Top right corner)
Tap
(LF: Low Freq.)
Tap
From top:
Unit,Gain, Freq.
Depth*³
A-scope
Frequency selection switchFrequency selection switch
Bottom
echo
Bottom
echo
Wat
er
temp.
scale
*2
*
1
: Requires ACCU-FISH
TM
compatible transducer on the network.
*
2
: Requires water temperature sensor.
*³: For full screen, you can adjust the depth font size in Home page→[Settings]→[Fish Finder]→
[User Settings]→[Digital Depth Size] menu.
Depth
scale
Depth
scale
Water temp. graph
*2
Fish
symbol
*1
Range
buttons
Fish
mark*¹
Fish
mark*¹
