44
Points/Boundaries
Points can be entered on the chart plotter display (radar, fish finder and weather displays also) to mark important
locations such as a good fishing spot. Point attributes (position, symbol type, color, etc.) are recorded to the Points
list. Also, boundaries can be set at the position desired (net position, area to avoid, etc.).
Tap where to enter a point.
The point is entered
on the screen.
Tap a point or the location
to set as destination.
On-screen point Selected location
On-screen pointOn-screen point
Points listPoints list
How to enter a point
Yellow line:
Shortest course from own
ship to the destination.
Purple line (with arrow):
Indicates course to go to
the destination.
How to set a point as destination
Destination point
If a point was tapped.
Sort the list by date, name, icon, color, range.
How to set a boundary
Tap the place where to set
a boundary.
Tap the shape to use for
the boundary.
[Area]/[Line]: Tap neces-
sary points to complete
the boundary, referring to
"Route" on the next page.
[Circle]: Drag icons to
adjust the size and
position, and then tap
[End Boundary].
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap the point to set as the destination.Tap the point to set as the destination.
㻙
Tap
Point filter Point filter Point filter Point filter Point filter
You can show/hide points on the screen by using the filter function.
Tap
Open [User Objects]
tab on the Layers menu.
Point filter options are shown
at the bottom right corner.
Point filter options are shown
at the bottom right corner.
.
㻻㻺
Turn the “Point Filters” to on
and set the filter by icon, color,
age, or name. For icon or color,
when MARK is selected no filter
is applied. For age, when Off is
selected, no filter is applied.
Tap
