EQUIPMENT LIST
Standard supply
Optional supply
*: Select the appropriate kit depending on the installation location and configuration.
Name Type Code No. Qty. Remarks
Antenna Unit SCX-20 - 1 For NMEA 2000
Installation Materials CP20-04600 000-036-768
1
(Select
one)
For roof mount kit of antenna
unit. Includes cable FRU-
NMEA-PMMFF (6 m).
CP20-04610 000-036-769 For pole mount kit of antenna
unit with cable FRU-NMEA-
PMMFF (6 m).
CP20-04620 000-036-770 For pole mount kit (w/Mast
Mounting Kit CP20-04605*) of
antenna unit. Includes cable
FRU-NMEA-PMMFF (6 m).
*: Includes Fixing Support Fix-
ture, Pipe and Hose Clamp
(25 to 35 mm), and 20A to 25A
(35 to 50 mm) diameter mast
installations.
Name Type Code No. Remarks
Cable Assembly FRU-NMEA-PMMFF-010 001-533-060 For NMEA 2000 net-
work, 1 m
FRU-NMEA-PMMFF-020 001-533-070 For NMEA 2000 net-
work, 2 m
FRU-NMEA-PMMFF-060 001-533-080 For NMEA 2000 net-
work, 6 m
Right Angle Mounting
Base
NO.13-QA330 001-111-910-10
Micro T-connector FRU-MM1MF1MF1001 001-507-050
Termination
Resistor (Micro)
FRU-MM1000000001 001-507-070
FRU-MF000000001 001-507-060
Roof Mount Kit* CP20-04602 001-556-170
Pole Mount Kit* CP20-04603 001-556-200
Mast Mounting Kit* CP20-04605 001-556-240 Requires CP20-04603.
Hose Clamp (Large) OP20-52 001-556-260 For 32A to 40A (35 to
50 mm) diameter mast
installations.
Bird-Repellent Fixture OP20-54 001-556-280 2 pcs.
Snow Cover Kit OP20-53 001-556-320
