1 – 4
1.4 Mutual Operation of Equipment
As noted earlier, the equipment in this radio console are interfaced by FURUNO's MIF radio
interface. For example, to transmit a message over the MF/HF DSC Terminal or NBDP Termi-
nal, the Tx and Rx frequencies and class of emission are automatically set on the SSB Radio-
telephone and then the message is transmitted.
Two printers are supplied and one is dedicated to the Inmarsat C. The other printer is shared by
up to four units: MF/HF DSC Terminal, NBDP Terminal, and external VHF DSC (maximum
two sets, option). It is automatically connected to one of those equipment on a first-come-first-
served basis. For example, if the MF/HF DSC Terminal is used (message transmission or recep-
tion), the printer is automatically connected to the MF/HF DSC Terminal and disconnects itself
from other equipment.
Connection between MF/HF DSC Terminal and NBDP Terminal
Suppose you transmitted a call over the MF/HF DSC Terminal and want to communicate with
the receiving station by the NBDP Terminal instead of the SSB Radiotelephone. If the MF/HF
DSC Terminal and NBDP Terminal were not connected you would have to set the several data
such as working frequency, communication mode, etc. manually on the NBDP Terminal. Be-
cause they are connected by the remote function, however, the data mentioned above are auto-
matically set on the NBDP Terminal via the MF/HF DSC Terminal.
1.5 Power On/Off
Turning on the system
For RC-1800F use the power switch at the lower left side of the console. For RC-1800T use
main switch on the switchboard and power switch on each AC/DC power supply.
1. Turn on breakers and switches on the AC/DC Power Supply in the following order:
1 100/200 VAC main power switch
2 PR-850AR AC input breaker
3 PR-850AR DC output breaker
4 All toggle switches (any order) on right side
2. Turn on power switches (any order) of all equipment in the console.
AC MAIN
24VDC OUT
(BACK UP)
AC IN
PR-850AR
1Main
Switch
3PR-850AR DC
Output Breaker
2PR-850AR AC
Input Breaker
4Toggle Switches
