1. OPERATIONAL OVERVIEW
1-4
2D positioning: Three satellites are used.
3D positioning: More than four satellites are used.
Unmonitored: The status of the receiving beacon station is unmonitored.
WER>10%: Word error rate of the receiving beacon station exceeds 10%.
Note: The screen refreshes slower in low ambient temperature.
To turn the power off, press the key.
1.3 How to Adjust the Brilliance of the Display and
Panel
1. Press the BRILL key to show the following setting window.
2. To adjust the display brilliance, use the cursorpad ( or ) or the BRILL key (set-
ting range: 0 to 15, default: 14 for day mode/6 for night mode).
3. To adjust the panel brilliance, use the cursorpad ( or ) (setting range: 0 to 9,
default: 7 for day and night modes).
4. Press the MENU/ESC key to close the setting window.
Note 1: The default settings for night mode is 6 for [Display] and 7 for [Panel]. If the
display is difficult to see when switching to the night mode, use the cursorpad () to
increase the display brilliance.
Note 2: Whenever the brilliance mode is changed, the last-used brilliance for the se-
lected mode is set.
GP-D2D GP-D3D GPS + Differential
GP-D2D (Yellow) GP-D3D (Yellow) GPS + Differential (WER>10%)
GP-D2D! (Yellow) GP-D3D! (Yellow) GPS + Differential (Unmonitored)
GP-Q2D GP-Q3D GPS + QZSS
GL-2D GL-3D GLONASS
GL-D2D GL-D3D GLONASS + Differential
GL-D2D (Yellow) GL-D3D (Yellow) GLONASS + Differential (WER>10%)
GL-D2D! (Yellow) GL-D3D! (Yellow) GLONASS + Differential (Unmonitored)
GN-2D GN-3D Multi
No Fix No fixed
Indication
System
2D positioning 3D positioning
Switch the color mode between
day mode and night mode.
Long-press to restore the
settings to default of day mode.
