1. INSTALLATION
1.1 Equipment Lists
Standard supply
Optional supply
Connection-verified transducers
Name Type Code No. Qty Remarks
Multi Beam
Sonar
DFF-3D - 1
Transducer B54 - 1 Select one.
B54: Thru-hull mount (bronze)
SS54: Thru-hull mount (stainless steel)
TM54: Transom mount
SS54 -
TM54 -
Spare Parts SP02-05601 001-033-740 1 set Fuses
Installation
Materials
CP02-09400 000-029-992 1 set • Power cable assy. (3.5 m)
• LAN cable assy. (5 m)
• Self-tapping screws
• Conductive tape
Name Type Code No. Remarks
Connector Kit for TX Sync OP02-86 001-205-780
Cable Assembly MOD-Z072-020+ 001-167-880-10 2 m, for HUB-101
Cable Assembly MOD-Z072-100+ 001-167-900-10 10 m, for HUB-101
Rectifier PR-62 000-013-484 100 VAC
000-013-485 110 VAC
000-013-486 220 VAC
000-013-487 230 VAC
AC/DC Power Supply Unit PR-241 -
Ferrite Core OP86-11 001-594-450 For use with PR-241
Type Remarks
CM54 Tank-equipped type.
165T-50/200-SS260 Integrated fish finder transducer.
165T-50/200-TM260
165T/265LH-PM488
165T/265LH-PM488-12P
165T/275LHW
165T/275LHW-12P
165T-PM542LM
165T-PM542LHW
