1. OPERATIONAL OVERVIEW
1-9
1.7 Choosing the Range
You may choose the speed range as follows:
1. Press the RANGE key to show the range setting window.
Range setting window (example: range setting window for tide vector display)
2. Within five seconds after completing step 1, operate the Setting Knob or the Cur-
sorPad to set the range.
Display and range to set
Setting Knob: Rotate clockwise to raise the range; counterclockwise to lower the
range.
CursorPad: Press or to raise the range; or to lower the range.
Display Range
Tide vector Tide speed range setting window appears. Set tide/tide differential
range (radius of vector display ring) appropriately.
Ship's speed The ship's speed range setting window shown depends on whether
SCALE SYNC in the DISP2 sub menu is set to ON or OFF.
ON: Port-starboard and fore-aft speeds are synchronized. The ship's
speed range setting window appears. Set speed appropriately.
OFF: The ship's speed range setting window appears. Set fore-aft
speed appropriately.
Graph The speed range setting window shown depends on the setting of
MODE in the DISP1 sub menu.
TIDE or TIDE DIF: The tide speed range setting window appears. Set
tide speed range (port-starboard of tide speed/tide differential graph)
appropriately.
SPEED: The ship's speed range setting window appears. Set ship's
speed range (fore-aft of ship's speed graph) appropriately.
Course plot The display scale setting window appears. Set display scale as appro-
priate.
Echo level Tide speed range setting window appears. Set tide and tide differential
range (radius of vector display ring) appropriately.
TIDE SPEED RANGE
KNOB OR CURSOR PAD: CHANGE SETTING
1.0
kn (0.5-10.0)
