FURUNO
CH-500/600
SP - 2 E1354S01E-M
240513
3.5 Full circle scanning period (s)
No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Range (m) 10 20 40 60 80 120 160 200 250 300 400 500 600 800 1000
Step
angle
6° 3.8 3.8 3.8 5.2 6.8 10.1 12.9 16.5 20.6 24.3 32.5 40.5 48.3 64.6 80.5
15° 3.7 3.7 3.7 3.8 4.8 5.6 7.2 8.4 10.1 12.0 15.0 18.2 21.6 27.8 34.1
24° 3.7 3.7 3.7 3.7 3.9 4.5 5.8 6.6 7.7 8.8 10.7 12.8 15.0 18.7 22.6
3.6 Horizontal mode control
Scanning angle 6° to 360°, 24° step
Scanning speed (step-angle) 6°, 12°, 15°, 18°, 21°, 24°
Tilt angle -5° to +90°(vertical), 1° step
Auto tilt setting ±2° to ±10°
3.7 Vertical fan mode control
Scanning angle 6° to 180°, 12° step
Scanning speed (step-angle) Normal: 3°, High speed: 6°
3.8 Transceiver beam width
CH-500 Frequency Horizontal (-3dB/-6dB) Vertical (-3dB/-6dB)
60 kHz: 15°/20° 12°/17°
88 kHz: 12°/16° 10°/13°
150 kHz: 7°/9° 7°/9°
180 kHz: 7°/9° 8°/10°
240 kHz: 6°/8° 6°/8°
CH-600 Frequency Horizontal (-3dB/-6dB) Vertical (-3dB/-6dB)
60 kHz: 16°/22° 14
°/20°
153 kHz: 7°/9° 5°/8°
85 kHz: 11°/15° 10°/14°
215 kHz: 5°/6° 4°/6°
3.9 Allowable ship’s speed 20 kn or less (15 kn during raise/lower operation)
3.10 Stabilization Built-in motion sensor (standard supply)
4 INTERFACE
4.1 Number of ports
Video signal output 1 port, HDMI, XGA
NMEA0183 (IEC61162-1) 2 ports, V1.5/2.0/3.0/4.0/4.1, 4800/9600/19200/38400 bps
NMEA2000 1 port
External KP 1 port, I/O
4.2 Data sentences
Input CUR, DBS, DBT, DPT, GGA, GLL, GNS, HDG, HDM, HDT, MDA,
MTW, RMC, VHW, VTG, ZDA
Output TLL
4.3 Output proprietary sentence
PFEC pidat
4.4 NMEA2000 PGN
Input 059392/904, 060160/416/928, 061184, 065240,
126208/720/992/996, 127250, 128259/267,
129025/026/029/033/291, 130310/311/312/316/577/821
Output 059392/904, 060928, 061184, 126208/464/720, 126993/996/998,
130822/823/828
