2. INSTALLATION AND INITIAL SETTINGS
2-24
3. Click [Network].
4. Click [Sentence].
5. Click [TT].
6. Check the appropriate radio button depending on the sentence for the data
source.
7. Do as follows according to the radio button that is checked at step 6.
• For [TTM (NavNet)] or [TTD/TLB/OSD (NavNet)]:
Enter the IP address(es) for the radar. Be sure to enter all IP addresses for the
radar to be assigned as the data source.
Note: All octets for each IP address must be entered. The IP address that has
one or more empty strings is invalid.
• For [TTM (TAG Block)] or [TTD/TLB/OSD (TAG Block)]:
Check the checkbox(es) for radar SFI (System Function ID). Be sure to check
all checkboxes for the radar to be assigned as the data source.
8. Click the [Commit & Reset] button to apply the settings.
All menu settings on the [Network] menu are applied by clicking the [Commit & Re-
set] button. Also, the AR navigation system application is automatically reset.
Model
ECDIS is included in the
system configuration
ECDIS is not included in the
system configuration
TTM TTD TTM TTD
FAR-147 Unconnectable Unconnectable [TTM (TAG
Block)]
Unavailable
FAR-158 [TTM (NavNet)] [TTD/TLB/OSD
(NavNet)]
[TTD/TLB/OSD
(TAG Block)]
FAR-27
FAR-28
FAR-3000 [TTM (TAG
Block)]
[TTD/TLB/OSD
(TAG Block)]
For [TTM (TAG Block)] or [TTD/TLB/OSD (TAG Block)]
For [TTM (NavNet)] or [TTD/TLB/OSD (NavNet)]
