1 Locking screws for the mounting bracket
2 Mounting bracket
3 [POWER IN] | Rubber panel plug for the power supply of the device with fuse holder
4 Display
5 [MODE] | Activates the main menu and toggles between menu items.
6 [SETUP] | Selects an option of the respective operating mode.
7 [UP] | Navigates upwards in a menu list, increases the displayed value by one.
8 [DOWN] | Navigates downwards in a menu list, reduces the displayed value by one.
9 [DMX IN] | DMX input, designed as an XLR panel plug, 3-pin
10 [DMX Out] | DMX output, designed as an XLR panel socket, 3-pin
11 [POWER OUT] | Rubber panel socket for providing a power supply for further devices
Connections and controls
20
LED BARbara 16, LED BARbara 24
LED Bar
