Getting started
► Connect one of the connectors of the data cable to the D-SUB socket or the DVI-D socket or the
DP socket of the monitor and secure the plug connection by tightening the retaining screws.
If you are using a display port data cable, you must switch the 0 W switch to
the Basic sett ing. If you are only using a DVI or VGA data cable, you can switch
the 0 W switch to the ECO setting to activate the 0 W standby.
The monitor automatically detects the input when only one signal source is connected.
► Insert one plug of the audi
olineintheAUDIOINsocketonthemonitor
and make sure it is proper
ly engaged.
► Plug the power cable supplied into the power conn ecto r of the monitor.
► Plug the supplied USB ca
ble into the USB IN s ocke t and the other end of
the cable into a USB s ock
et of the computer.
Connect the USB keyboa
rd a nd USB mouse directly to the PC, as the USB connector
socket of the monitor
is switched off in energy-saving mode.
► Secure th e cover over the connections.
A lock (Kensington Lock) can be mounted in the security s lot to protect the monito r
against theft. A Kensington lock is not supplied with the monitor.
Connecting cables to the computer
Information on the compu ter connections and interfaces is contained in the
operating manual for your computer.
► Connect the data cable to the (active) monitor port on the compu ter and secure
the plug-in connection by tightening the safety screws.
► Insert the other plug of the audio cable in the audio output of the computer.
► Plug the power connector of the monitor into a properly grounded mains outlet.
► Plug the power connector of the computer into a properly ground ed mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is active as standard.
Fujitsu Technology Solutions 17
