En-10
WARNING!
●
Never place fi ngers or foreign objects inside
the outlet ports, since the internal fan oper-
ates at high speed and could cause per-
sonal injury.
●
Always use the Remote controller’s
SET button to adjust the vertical airfl ow
louvers. Attempting to move them man-
ually could result in improper operation;
in this case, stop operation and restart.
The louvers should begin to operate
properly again.
●
When used in a room with infants, chil-
dren, elderly or sick persons, the air
direction and room temperature should
be considered carefully when making
settings.
●
When indoor unit is embedded in a wall,
airfl ow is fi xed to horizontal direction
5
.
Please ask the service personnel to
perform the embedding in a wall.
Vertical Air Direction Adjustment
Press the SET button (Fig. 5
Q
).
Each time the button is pressed, the air direction range will change as follows:
1
2
3
4
5
The Remote controller’s display does
not change.
●
Use the air direction adjustments within the ranges shown above.
●
The vertical airfl ow direction is set automatically as shown, in accordance with the
type of operation selected.
During Cooling/Dry mode : Upward fl ow
1
During Heating mode : Horizontal fl ow
4
●
During AUTO mode operation, for the fi rst minute after beginning operation, airfl ow
will be upward
1
; the air direction cannot be adjusted during this period.
●
During Heating mode operation, airfl ow will be upward
1
when the temperature of
the air issued from the indoor is low.
Right-Left Adjustment
Adjust the Right-Left louvers.
●
Move the Right-Left louvers to adjust airfl ow in the direction you prefer.
ADJUSTING THE DIRECTION OF AIR CIRCULATION
Vertical (up-down) direction of airfl ow is adjusted by pressing the Remote controller’s SET button. Horizontal (right-left) airfl ow direc-
tion is adjusted manually, by moving the Airfl ow Direction Louvers.
Whenever making horizontal airfl ow adjustments, start air conditioner operation and be sure that the vertical air direction louvers are
stopped.
WARNING!
●
Always adjust the Right-Left louvers when
the damper is open. Opening the damper
forcibly with hands can cause damper of
malfunction.
1
2
3
4
5
9378532052_OM.indb 109378532052_OM.indb 10 7/2/2013 10:20:10 AM7/2/2013 10:20:10 AM
