EN
FUAVE SF130ACMB | SF130ACMW
Setting the height of the appliance
The height of the appliance can be adjusted by removing or installing an extension piece between the fan motor and the base.
1. Remove the plug from the socket.
2. Loosen the fan motor anti-clockwise from the extension/base.
Setting the appliance lower
1. Loosen the extension piece anti-clockwise from the extension piece or base.
2. Tighten the fan motor clockwise in the extension/base.
Setting the appliance higher
1. Tighten the extension piece clockwise in the base.
2. Tighten the fan motor clockwise in the extension piece.
5. Cleaning and maintenance
5.1. Important information
Carry out cleaning and maintenance as indicated. This extends the life of the appliance and will keep it working properly.
WARNING!
ELECTROCUTION HAZARD DUE TO SHORT CIRCUIT.
• Before cleaning and maintenance, turn off the appliance with the power button and remove the plug from the socket.
Ensure that the plug is not accidentally plugged into the socket during the activities.
• Never spray the appliance and make sure no water gets into it.
• Cleaning and user maintenance must not be carried out by children without supervision.
11
NOTICE!
• Risk of damage to the appliance. Never use aggressive cleaning agents, white spirit, detergents, impregnated wipes or
other cleaning solutions. These can damage the housing and appliance.
5.2. Cleaning the housing
1. Press the off switch to switch off the device.
2. Remove the mains plug from the socket.
3. Use a soft damp cloth to wipe the housing.
4. Then wipe the appliance dry with a soft cloth.
5.3. Thorough cleaning
Depending on the degree of use and the operating environment, dust and other dirt may have ended up in the air inlet and
outlet. In this case, more thorough cleaning is required.
1. Press the off switch to switch off the device.
2. Remove the mains plug from the socket.
3. Loosen the screw from the guard with a screwdriver.
4. Detach the guard clip from the rear guard and remove the front guard.
5. Hold the fan blade and loosen the blade nut clockwise from the fan motor shaft.
6. Remove the blade nut and fan blade from the fan shaft.
7. Use a soft damp cloth to wipe the fan blade and guards.
8. Then wipe the fan blade and guards dry with a soft cloth.
9. Follow the steps in the 3.3.Installing the appliance section to reassemble the appliance.
