8
INSTALLATION
Door Opening
Position your unit to allow easy access to
a counter or table when removing food.
For the best use of drawers and freezer
baskets, position the appliance where
both doors can fully open.
NOTE
The doors are designed to shut by
themselves within a 20 degree opening.
To remove the toe grille
1. With both doors closed, unfasten
the right and left side clips of toe
grille from the bottom hinge groove.
2. Open both doors. Press firmly on the
top of the toe grille until the top of
the toe grille pops o.
3. Pull the toe grille outward toward
your body and o of the lower hinges.
1
2
3
2
3
1
Removing Toe Grille
Guidelines for final positioning
of your unit:
• Rest all 4 corners of the cabinet
firmly on the floor.
• Level the cabinet at the front and
rear so the front is raised ¼" (6 mm)
above the rear to ensure the door will
open/close and seal properly.
• Align the doors with each other
and level.
Meet all of these conditions by
raising or lowering the adjust-
able leveling feet.
To level the cabinet using the front
leveling feet:
1. Open both doors and remove
the toe grille (see Toe Grille
Installation and Removal in the
INSTALLATION section).
2. Level the cabinet at the front and
rear so the front is raised ¼" (6 mm)
above the rear. Close the doors. Use
an adjustable wrench to loosen the
feet (A). Once you have lowered
the leveling feet slightly, use the
wrench on the nut (B) to lower
(counterclockwise) or raise (clockwise)
the front of the cabinet ensuring the
unit is sitting flat on the floor.
3. Ensure both doors are bind free
with their seals touching the cabinet
on all 4 sides.
1/4”
(6 mm)
1/4”
(6 mm)
A
B
