CAUTION!
Wear gloves and safety goggles. Use ex‐
treme caution when installing these handles.
The rounded end of the handles may be
sharp (some models).
Metal handle
To attach the refrigerator/freezer metal handle:
1. Open the door.
2. Place the rounded part of the handle onto
the shoulder screw on the face of the door
and align the 2 holes:
• for the refrigerator: at the top of the
handle with the 2 holes at the top of the
door.
• for the freezer: at the bottom of the
handle with the 2 holes at the bottom of
the door.
Do not tighten the set screw yet.
3. Install the 2 screws into:
• the top of the refrigerator handle:
A
B
C
D
A. Shoulder screw
B. Screw
C. Handle
D. Set screw
• the bottom of the freezer handle:
B
C
D
A
A. Screw
B. Shoulder screw
C. Set screw
D. Handle
4. Tighten the set screw on the rounded part
of the handle until the handle is flush with
the door, then tighten another 1/2 turn
For professional models:
With the door open, place the handle over the
shoulder screw. Tighten the set screws.
12
DOOR HANDLE INSTALLATION
