13
WATER SUPPLY CONNECTION
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100 psi.
• A water supply line made of ¼" (6.4
mm) OD, copper or stainless steel
tubing. To determine the length of
tubing needed, measure the distance
from the ice maker inlet valve at the
back of the refrigerator to your cold
water pipe. Then add approximately
7� (2.1 m), so the refrigerator can be
moved out for cleaning.
To Connect Water Supply Line To Ice
Maker Inlet Valve
1. Disconnect the refrigerator from
electrical power source.
2. Place the end of the water supply
line into a sink or bucket. Turn ON
the water supply and flush the supply
line until the water is clear. Turn OFF
the water supply at the shuto valve.
3. Remove the plastic cap from the wa-
ter valve inlet and discard the cap.
4. If you use copper tubing - Slide the
brass compression nut, and then
the ferrule (sleeve) onto the water
supply line. Push the water supply
line into the water valve inlet as far
as it will go (¼"/6.4 mm). Slide the
ferrule (sleeve) into the valve inlet
and finger tighten the compression
nut onto the valve. Tighten another
half turn with a wrench; DO NOT
overtighten. See Figure 1.
• A shuto valve to connect the water
supply line to your household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the ice maker
inlet valve.
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the unit from electrical pow-
er source before connecting a water
supply line to the appliance.
CAUTION
To Avoid Property Damage:
• Use Copper or Stainless Steel braid-
ed tubing for the water supply line.
Frigidaire does not recommend wa-
ter supply tubing made of ¼" plastic.
Plastic tubing greatly increases the
potential for water leaks, and the
manufacturer will not be responsible
for any damage if plastic tubing is
used for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to soft
water, ensure that the softener is
maintained and working properly.
NOTE
Check with your local building authori-
ty for recommendations on water lines
and associated materials prior to in-
stalling your new refrigerator. Depend-
ing on your local/state building codes,
we recommend for homes with existing
valves its Smart Choice
®
water line kit
5304490728 (with a 6�Stainless Steel
Water Line) and for homes without an
existing valve, we recommend Smart
Choice
®
water line kit 5304490717 (with
a 20�copper water line with self-tap-
ping saddle valve). Please refer to
Frigidaire.com for more information.
IMPORTANT
Ensure your water supply line connections
comply with all local plumbing codes.
