11
To remove the refrigerator door:
1. Remove the 3 screws from the cover
over the door hinge.
2. Lift hinge cover straight up and o.
3. Release the wires from the routing clip.
Disconnect the multi-wire cable
connector located above the top
hinge. Press the cable and lock and
separate the 2 cables.
4. Trace lightly around the hinge with a
pencil. This makes reinstallation easier.
5. Remove the toe grille (see Toe Grille
Installation and Removal).
6. Detach the water tube from the
connector located below the freezer
door. The connector releases when
you press its outer sleeve inward.
DOOR REMOVAL
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury.
To Disconnect
1. Press outer ring against face of
fitting
2. Pull to
remove tube
Insert tube and push until mark
touches face of fitting
To Connect
IMPORTANT
To prevent wire damage, ensure the
wires are rerouted through the routing
clip when reassembling the hinge cover.
7. Remove the 2 screws from the top
hinge. Remove the hinge pulling the
multi-wire cable through it. Lift the
door o the bottom hinge.
8. Remove the 2 bottom hinge screws
and hinge if necessary.
9. Lay the door on its side to avoid
damage to the water tube extending
from the bottom hinge.
To reinstall the refrigerator door, reverse
the above steps.
