CAUTION!
Before manually cleaning any part of the oven, be sure all controls
are turned off and the oven is cool. The oven may be hot and can
cause burns. Remove all racks and accessories from the oven
before cleaning. Ammonia must be rinsed before operating the
oven. Provide adequate ventilation.
Cleaning Porcelain Enamel Oven
The oven interior is porcelain on steel.
To clean the interior use oven cleaners.
To remove heavy soil:
1. Place the dish of ammonia in the oven.
Let it sit overnight or for several hours with the oven door closed.
Clean softened dirt spots using hot, soapy water.
Rinse thoroughly with water and a clean cloth.
2. If soil remains, use a nonabrasive scouring pad or nonabrasive
cleaner.
If necessary, apply an oven cleaner following the manufacturer's
instructions.
Do not mix ammonia with other cleaners.
3. Clean any soil from the oven frame, the door liner outside the oven
door gasket, and the small area at the front center of the oven
bottom.
Use hot, soapy water for cleaning.
Rinse well with clean water and a cloth.
Aluminum Foil, Aluminum Utensils, and Oven Liners
WARNING!
Never cover any slots, holes, or passages in the oven bottom or
cover an entire oven rack with materials such as aluminum foil.
Doing so blocks airflow through the oven and may cause carbon
monoxide poisoning. Aluminum foil linings may trap heat, causing
a fire hazard.
• Protective liners- Do not use aluminum foil to line the oven bottom.
High heat can melt it, damaging the oven and reducing air
circulation, leading to poor baking results. Only use aluminum foil as
recommended in the manual to avoid electric shock or fire risks
• Aluminum utensils- Aluminum utensils have a lower melting point
than other metals. Use aluminum pots and pans with care.
• Oven racks- Do not cover oven racks with aluminum foil. It restricts
heat and airflow, affecting cooking results.
7.3 Replacing the Oven Light
CAUTION!
Be sure the oven is unplugged and all parts are cool before
replacing the oven light.
The interior oven light is located at the rear of the oven cavity and is
covered by a glass shield. The glass shield must be in place whenever
the oven is in use.
NOTE
Wear a cotton glove or use a paper towel when installing a new
bulb. Do not touch the new bulb with your fingers when replacing.
This will shorten the life of the bulb.
To replace the oven interior light bulb:
1. Turn electrical power off at the main source or unplug the
appliance.
2. Remove interior oven light shield by turning a quarter turn counter-
clockwise.
3. Replace bulb with a new T-4 type Halogen 25 watt appliance bulb.
4. Replace glass oven light shield by rotating clockwise.
5. Turn power back on again at the main source (or plug the
appliance back in).
Be sure to reset the time of day on the clock.
7.4 Caring for Your Glide Racks
CAUTION!
Handle oven racks only when they are cool. After cooking or after
the fresh-clean cycle, racks will be very hot and cause burns.
IMPORTANT
• Remove all oven racks, including ladder racks, before starting a
clean cycle.
• Do not use cooking oil, cooking spray, or other oil-based
lubrication products on the glide rack extension tracks. Use only
the graphite lubrication in this area. To order graphite
lubrication. contact your installer, servicer or dealer.
• It is important that the parts of the rack that contact the oven
sides always have a light coating of vegetable oil. Apply a thin
layer of vegetable oil to the sides of the rack after every fresh-
clean cycle and when the rack becomes difficult to reposition in
the oven.
To lubricate the glide rack:
1. Remove the rack from the oven and place the rack on a large flat
surface covered with newspaper or scrap cloth. Fully extend the
rack.
2. Wipe away debris and crumbs from the glide track using a cloth or
sponge.
3. Shake graphite lubrication very well before applying. Apply to
loading guides, and rotation pin. Repeat on both sides of the glide
rack.
4. Extend and return the glide rack several times along the tracks to
distribute the lubrication.
5. Turn the rack upside down and apply graphite lubrication to the
insides of the loading guides.
ENGLISH 25
