Oven Problems

Occurrence Possible cause Solution

Poor baking results. Many factors affect baking results. Use proper oven rack position. Center food in the oven and space pans to allow air to cir‐

culate. Preheat the oven to the set temperature before placing food in the oven. Adjust the

temperature and baking time recommended in the recipe.

Flames inside oven or smoking from

oven vent.

Excessive spills in oven.

Grease of food spilled onto the oven bot‐

tom or oven cavity.

Wipe up excessive spills before turning on the oven.

If flames or excessive smoke are present when using broil, refer to Setting Oven Controls.

Oven smokes excessively when boil‐

ing.

Incorrect setting. Refer to Setting Oven Controls.

Meat to close to the broil element or burn‐

er.

Reposition the broil pan to provide proper clearance between the meat and broil element

or burner. Remove excess fat from meat. Cut remaining fatty edges to prevent curling, do

not cut into lean.

Grease build up on oven surfaces. Regular cleaning is necessary when you broil frequently. Grease or food splatters cause

excessive smoking.

Oven control panel beeps and dis‐

plays any F or E code error.

Oven control detected a fault or error con‐

dition.

To clear the error press the OFF key on the control panel. Once you clear the error code,

try the bake or broil function. If the F or E code error repeats, turn off the power to the ap‐

pliance and wait 5 minutes, and then repower the appliance. Set the clock with the correct

time of day, and try the bake or broil function again. If the fault recurs, press the OFF key

to clear.

Oven portion of appliance does not

operate.

The regulator gas is OFF. Make sure the regulator gas is turned ON. Refer to Installation Instructions.

The time of day is not set. The clock must be set in order to operate the oven. Refer to Setting Oven Controls.

Desired function is not set. Make sure the oven controls are set properly for the desired function. Refer to Setting

Oven Controls and this checklist.

Convection fan does not rotate. Oven door is open. The convection fan turns off if the oven door is open when convection is active. Close the

oven door.

On gas models, the convection fan begins to rotate about 6 minutes into the preheating

process.

Cooktop Problems

Occurrence Possible cause Solution

Surface burners do not ignite. Surface control know was not completely

turned to .

Push in and turn the surface control knob to until the burner ignites and then turn the

control knob to the desired flame size.

Burners ports are clogged. With the burner OFF and cool, use a small-gauge wire or needle to clean the burner head

slots and ignition ports. Refer to Care and Cleaning.

Range power cord is disconnected from

outlet (electric ignition models only).

Make sure the power cord is securely plugged into the power outlet.

Circuit is broken. Check breaker box or fuse box.

Electrical power outage. Burners may be lit manually. Refer to Setting Surface Controls.

Surface burner flame uneven or only

part way around burner cap.

Burners slots or ports are clogged. With the surface burner OFF and cool, clean ports with a small-gauge wire or neddle. If

moisture is present after cleaning, lightly fan the flame and allow the burner to operate until

flame is full.

Burners caps are not seated properly. Check that all burner caps are level and seated correctly on the burner heads. Refer to

Care and Cleaning.

Surface burner flame is too high. Surface control knob is set to high. Adjust to lower flame setting.

Burners caps are not seated properly. Check that all surface burner caps are level and seated correctly on the surface burner

heads. Refer to Care and Cleaning.

Incorrect L.P. conversion. Refer to L.P. conversion kit instructions to correct.

Surface burner flame is orange. Dust particles in main gas line. Allow the burner to operate a few minutes until flame turns blue. In coastal areas, slightly

orange flame is unavoidable due to salt content in the air.

Incorrect L.P. conversion. Refer to L.P. conversion kit instructions to correct.

Self-Clean Problems

Occurrence Possible cause Solution

Self-clean does not work. Oven control not set properly. Refer to Setting Oven Controls.

Oven racks discolored or do not slide

properly.

Oven racks left in oven during self-clean. Remove oven racks from the oven cavity before starting self-clean cycle. Clean by using a

mild abrasive cleaner following manufacturer's instructions. Rinse with clean water, dry,

and replace in oven.

26 ENGLISH
