NOTE
Fresh food door must be removed before
removing Freezer door.
WARNING
Make sure unit is unplugged before
beginning the door removal process.
7
DOOR REMOVAL
Screws
Lift door
off lower
hinge
Lower
Hinge
Lift door off
lower hinge
1 Use screwdriver to remove center hinge.
2 Lift freezer door o lower hinge to remove
from unit.
Getting through narrow spaces
If your refrigerator will not t through an
entrance area, you can remove the doors.
Check rst by measuring the entrance.
Lower
Hinge
Door
Stop
Washer
Hinge
Pin
Center
Hinge
Screws
Lower
Hinge
Lift door
off lower
hinge
3 Center
Hinge
Screws
Corresponding
hole on bottom
of freezer door
To remove the freezer door
Hinge
Cover Screws
Top Hinge
Cover
Hinge
Screws
Multi-Wire
Cable
Top
Hinge
Tools Necessary:
Phillips
TM
Head
Socket
Wrench Set
To remove the fresh food door:
1 Remove 2 hinge cover screws and top
hinge cover
2 Lift hinge cover straight up and o.
3 Remove the 3 screws from the top hinge.
4 Disconnect all electrical connections.
5 Lift the door o of the center hinge and
set it aside.
To reinstall the freezer door
1 Place Freezer door on lower hinge pin.
Align hole on bottom of freezer door with
lower hinge pin.
2 Insert Center hinge into top of freezer door.
3 Reattach 3 center hinge screws.
