9
Light button
Your appliance has exterior lights under the refrigerator doors and the Custom-
Flex™ Temp drawer. Press and hold the light button for 5 seconds to enable the
lights. The lights will remain on until you disable them by pressing and holding
the button for 2 seconds.
10
Freezer com‐
partment but‐
ton
Select Freezer compartment to change the temperature.
Select + / - buttons to set the temperature.
Freezer control range: -6°F (-21°C) to +6°F (-15°C).
11
Temp F-C Touch to switch from Fahrenheit to Celsius.
12
Default Set‐
ting
Press and hold for 3 seconds to reset to Factory settings.
Display modes
Your display is equipped with a sleep and
lock mode to prevent accidental changes
to the appliance settings during opening
and closing of the doors. When both doors
are closed, the display is in the sleep
mode. When either door is first opened,
the display is in lock mode where all the
current settings are visible but dimmed.
Pressing any button on the display awakes
the display and a tone plays. All settings
then are fully lit. Touch the display again to
change any setting.
If there is no button pressed for 10
seconds while any door is open, the
display comes back to lock mode by
default.
9.1 Setting cooling temperatures
NOTE
The recommended settings for a
product installed in a kitchen is 37°F
for the fresh food compartment and
0°F for the freezer.
Press + or - to adjust the temperature to
the desired setting. The temperature
setting begins to blink with the first touch.
The display times out after 10 seconds
and then returns to the basic display.
9.2 Clear Alerts
Door Open
If you leave freezer or refrigerator doors
open for 5 minutes or more, the alarm
sounds and the Door Open indicator
illuminates on the control display. Press
Clear Alert to reset the alarm.
High Temp Alarm
High Temp illuminates next to Clear Alerts.
The alarm plays every 60 seconds. Press
Clear Alerts to acknowledge the alarm.
The highest temp value displays when you
first acknowledge the alarm.
Power Outage
In the event of a power outage, Power
Outage illuminates. Press Clear Alerts to
acknowledge the alarm. Other modes may
be turned off until you acknowledge the
alarm. While Power Outage displays on
the control display, the unit continues
normal operation. High Temp may also
illuminate until you have reached a safe
operating range temperature.
9.3 Sabbath Mode
NOTE
While in Sabbath Mode, neither the
lights, dispenser, nor the control panel
will work until Sabbath Mode is
deactivated. Refrigerator stays in
Sabbath Mode after power failure
recovery. It must be deactivated with
the buttons on the control panel.
NOTE
Although you have entered the
Sabbath Mode, the ice maker will
complete the cycle it had already
initiated. The ice cube compartment
will remain cold and new ice cubes
can be made with standard trays.
The Sabbath Mode is a feature that
disables portions of the refrigerator and its
controls in accordance with observance of
the weekly Sabbath and religious holidays
within the Orthodox Jewish community.
Turn Sabbath mode ON and OFF by
simultaneously pressing and holding both
— and Temp F-C for five seconds. The
display shows Sb while in Sabbath mode.
ENGLISH 23
