15
CAUTION
Drawer is heavy. Use caution when lifting.
Removing Freezer the Drawer
1. Remove the four hex head drawer
screws (two per side) securing the
drawer to the slide assemblies.
2. Lift up drawer to remove.
Remove
Hex Head
Drawer
Screw
CAUTION
Do Not loosen or remove the 3 hex screws.
DOOR REMOVAL
NOTE
To locate the pin, look inside the drawer. The
pin is next to the door liner and the slides.
Not all parts are shown in the illustration.
Replacing Freezer Drawer
1. Extend the freezer slides from the unit.
2. Carefully align support pin with
hooks on end of freezer slides, and
then lower freezer door onto slides.
3. Replace the four hex head screws
securing the slides to the door (two
on each side) and tighten.
