PL
ACEMENT OF THE MOUNTING PLATE
1
I
nstallation Instructions
Find the studs, using one of the
following methods:
A. Stud finder – a magnetic device which
locates nails.
B. Use a hammer to tap lightly across the
mounting surface to find a solid sound.
This will indicate a stud location.
After locating the stud(s), find the center by
probing the wall with a small nail to find the
edges of the stud. Then place a mark
halfway between the edges. The center of
any adjacent studs should be 16w (40.6 cm)
or 24w (61 cm) from this mark.
Draw a line down the center of the studs.
THE MICROWAVE MUST BE CONNECTED
TO AT LEAST ONE WALL STUD.
1
REMOVING THE
MICROWAVE OVEN FROM
THE CARTON/REMOVING
THE MOUNTING PLATE
FINDING THE WALL STUDS
B
.
A
.
2
Wall
Studs
Center
3
Carton
Pull the carton up and off the oven.
2
Styrofoam
3
1
Screws
Screws
Mounting Plate
4
Cut the middle of the outer protective
plastic bag to remove
the m
ounting
p
late
5
Remove the screws from each end of the
mounting plate. This plate will be used as the
rear wall template and for mounting.
Reinstall the screws into the holes where
they were removed.
EN-6
Remove the installation instructions,use
and care, exhaust adapter, turntable ring,
shelf, filters, glass tray and the small
hardware bag. Do not remove the
Styrofoam protecting the front of the oven.
please note: Do Not Remove plastic plug
protective cover until just before hanging
the unit.
Exhaust Adapter
Small Hardware Bag
Filters and Turntable
Ring below glass tray
Glass Tray
Fold back all 4 carton flaps fully against
carton sides. Then carefully roll the oven
and carton over onto the top side. The
oven should be resting in the Styrofoam.
