15INSTALLATION INSTRUCTIONS
3. Close the window sash securely against
the window slider kit.
5. To secure lower sash in place, attach
Safety lock with 5/8" (16mm) screws as
shown.
4. Drive four 1/2" screws to secure the
window slider kit to the window.
1/2"screws
6. Cut the non-adhesive window foam to an
appropriate length and seal the open gap
between the upper window sash and lower
window sash.
Window Foam
2. Open the window sash and place the
window slider kit on the window stool.
Attach the window slider kit to the window
stool. Adjust the length of the window slider
kit according to the height of window. Use
the four screws that packed with the window
slider kit panels to fix the length of the
window slider kit.
window sill
Window slider kit
1. Cut the adhesive sealing strip to the proper
lengths and attach them to the window
frame.
Installation in a sliding sash window
Sealing strip
(adhesive type)
Screws
Note: Not all installations require all 3
window kit panels and four screws. Select
according to the actual situation.
