25OPERATING INSTRUCTIONS
Note: To ensure all condensate residue has
been removed, tilt the unit by lifting it slightly
upwards from the front until no more
condensate comes out from the drain outlet.
Put a drip tray (not supplied) under the
continuous drain outlet, then unscrew the
drain cap to allow the condensate to flow
into the drip tray. Replace the drain cap to
the continuous drain outlet when no
condensate flows out.
Put the drip tray under the bottom drain
outlet, then remove the rubber stopper from
the drain outlet, to allow the condensate to
flow into the drip tray. If your drip tray can’t
hold all the condensate, a number of fills will
be needed.
Replace the drain cap to the bottom drain
outlet when no condensate flows out.
Emptying the condensate residue inside the
unit during winter storage.
Bottom
Drain Outlet
Drip tray
Drain cap
Note:
Do not drain condensate outside when
outside temperature is below 32°F (0°C).
• Lead the other end of the 1/4" drainage
hose to a drain that is not 16ft(5m) higher
than the heat pump drain outlet.
• Insert the rubber head into the outlet. Then
screw the sealing cap into the heat pump
drain outlet.
heat pump
drain outlet
rubber head
sealing cap
1
2
