11
Figure 9
90°
Figure 8
19. Slide the door onto the bottom hinge
pin at 90° to the freezer cabinet and
close the door (see Figure 8).
20. Using a Phillips™ screwdriver or a
5/16" wrench, secure the top hinge
using three 5/16" screws. Replace
the top hinge cover (see Figure 9).
21. Plug the freezer power cord back
into the electrical outlet, and turn
the freezer temperature control to
the Recommended setting.
DOOR REMOVAL/REVERSAL
(UNITS WITH TEMPERATURE CONTROL INSIDE)
