10
DOOR REMOVAL
or
or
Tools Necessary:
Socket
Wrench Set
Adjustable
Wrench
5/16"
(8mm)
Fixed
Wrench
Pan Head
Quadrex
MSX12
Top Hinge
Screw
MSX16
Quadrex
Center
Hinge
Phillips™
Head and
Flat Head
Screwdriver
Hammer
Door Removal/Reversal
(some models)
1. Unplug
your refrig-
erator.
2. Remove the
top hinge
cover (some
models--see
Figure 1A).
For models
without the
hinge cover,
go to step 3.
CAUTION
Be sure the doors are set aside in a
secure position where they cannot fall
and cause personal injury.
3. Using a 5/16 in. socket, loosen the
3 screws from the top hinge (see
Figure 2).
Figure 1
A
B
Figure 2
4. Carefully open the freezer door. Lift
the loosened the top hinge and lift
the door o of center hinge pin. Set
the door aside.
NOTE
The direction in which your refriger-
ator doors open (door swing) can be
reversed, from left to right or right to
left, by moving the door hinges from
one side to the other. Reversing the
door swing should be performed by a
qualified person.
IMPORTANT
Before you begin, turn the refrigera-
tor temperature control to OFF and
remove the electrical power cord from
the wall outlet. Remove any food from
door shelves.
