8
29. Flip freezer door over and remove the
screw from the door closer using a Phillips
Head screwdriver and set aside (see
Figure 7A).
30. Pry out the center hinge bearing from the
freezer door with a straight screwdriver
(see Figure 7B).
31. Install the center hinge bearing on the
opposite side of the door (see Figure 7C).
32. Flip the door closer over and install on the
opposite side of the door (see Figure 7C).
18. Flip refrigerator door over and remove the
screw from the door closer using a Phillips
Head screwdriver and set aside (see
Figure 6A).
19. Pry out the bottom hinge bearing from the
refrigerator door with a straight screwdriver
(see Figure 6B).
20. Install the bottom hinge bearing on the
opposite side of the door (see Figure 6C).
21. Flip the door closer over and install on the
opposite side of the door (see Figure 6C).
DOOR REMOVAL/REVERSAL INSTRUCTIONS
(SOME MODELS)
22. Lower refrigerator door over the bottom
hinge pin and close door.
23. Attach center hinge with the three center
hinge screws using a T20 Torx Head
screwdriver.
24. Screw in and tighten the center hinge pin
using an adjustable wrench.
25. Pry out the top hinge bearing from the
top of the freezer door with a straight
screwdriver.
26. Pry out the top hinge bearing plug from
the opposite side of the freezer door with
a straight screwdriver.
27. Install the top hinge bearing in place of
the plug removed in previous step.
28. Install the top hinge bearing plug on the
opposite side of the door.
Refrigerator
Door Bottom
A
B
C
Figure 6
Freezer
Door Bottom
A
B
C
Figure 7
33. Lower freezer door over the center hinge
pin and close door.
34. Attach the top hinge with the three screws
using a Phillips Head screwdriver or 5/16”
wrench.
35. Tighten the top hinge screws.
