16
IMPORTANT
Before starting a cycle, run hot water to
clear cool water from pipe.
Rinse Aid
Rinse aid grRinse aid greaeatly imprtly improovves drying andes drying and
rreduceduces wes waatter spots.er spots. With it water
sheets” o dishes rather than forming
water droplets that cling and leave spots.
A dispenser, located next to the
detergent cup, automatically releases a
measured amount of rinse aid during the
last
rinse. If spotting and poor drying are
problems, increase the amount of rinse
aid dispensed by below steps:
1.Open the door when dishwasher is in
standby mode.
2.Within 60 seconds after opening the
door, press and hold
Quick button for
more than 5 seconds to enter the set
mode. The rinse aid indicator blinks.
3.Press Quick
button again to select the
proper set according to your using habits,
the setting will change in the following
sequence: 34 5 1 2 3. The higher
the number, the more rinse aid the
dishwasher uses.
4.Without operation in 5 seconds to
complete the setup and exit the setting
mode.
Turn on hot water faucet nearest
dishwasher for several minutes to
clear cool water from pipes.
Hold a candy or meat thermometer
in the water stream to check the
temperature.
If temperature is below 120°
F (49°
C), have a qualified person raise the
hot water heater thermostat setting.
Water Pressure
The hot water line to dishwasher must
provide water pressure between 20 and
80 psi.
Low Water pressure may occur when
laundry or showers are in operation. If
you experience poor wash performance
you may need to wait until water use is
reduced before starting dishwasher.
Water Temperature
Hot water is needed for best
dishwashing and drying results. Water
entering dishwasher should be at least
120°F to 150°F(49 to 66
)to give
satisfactory results.
To check water temperature entering
dishwasher:
CARE AND CLEANING
1. Lift up the end tab
of rinse aid cover to
open.
2. Fill the rinse aid
dispenser with liquid
rinse aid until full.
DO NOT overfill.
NOTE:
Use the viewing port when filling the rinse
aid reservoir.
Under normal conditions, you will need to
fill the rinse aid dispenser approximately
once a month. Rinse aid is released
through an opening in the dispenser. You
do not need to wait until the dispenser is
empty to refill it. Try to keep it full, but be
careful not to overfill it.
To refill the rinse
aid dispenser
WARNING
Do not fill the reservoir above the full
level indicator. Excess rinse aid can
overflow during the wash cycle.
3. Press the rinse aid cover down
firmly to close.
