37
1. Use a putty knife or flat screwdriver to
pry up the screw hole cover in the upper
left corner of the appliance and the top
hinge cover in the upper right corner of
the appliance.
2. Unscrew the top hinge using a
screwdriver or 8 mm wrench (hold the
top door in your hand while doing this).
3. Remove the door from the lower hinge.
NOTE: When you remove the door, do
attention to washers located between the
hinge lower and bottom of the freezer that
can get stuck in the door. Don't lose them.
4. Loose screw ② and screws ⑤, detach
part ① and part ③ part ④. Replace
part ① to the right side and tighten
securely with screw ②. Replace part ③
and part ④ to the left side and tighten
securely with screws ⑤.
① Support block for door frame
② Self-tapping screw
③ Door stopper
④ Limit block
⑤ Self-tapping screw
5. Lay the freezer on soft foam packaging
or similar material. Remove part ① part
②, and part ③ by unscrewing the
screws ④.
① Screw cover
② Adjustable bottom feet part
③ Right lower hinge part
④ Screws.
6. Replace part ③ to the left side and fixing
it with the screws ④. Replace part ①
and part ② to another side and fixing it.
