SPECIFICATIONS

Cool w/ Electric Heat (265V)

Figure 202

Model PZE09R3SC PZE12R3SC

Power supply V-Ph-Hz 265V/60Hz 265V/60Hz

Power supply type Single-phase power（1Ph（ Single-phase power（1Ph（

Cooling

Capacity Btu/h 9000 12300

Input W 780 1150

EER Btu/h.W 11.5 10.7

Amps A 3.1 5.1

Electric heating

Capacity (230/208V) Btu/h 12000 12000

Power input (230/208V) W 3650 3650

Rated current (230/208V) A 13.8 13.8

Sensible Heat Ratio

84.8% 75.7%

Moisture

Removal pints/hr 1.1 2.8

MCA A 20 20

MOP

A 15 15

Power factor 1.0 1.0

Max. input consumption W 1040 1400

Max. current A 4.4 5.9

Compressor

Compressor KSN71U11VDZ KSM103U11UFZ

Type rotary rotary

Brand GMCC GMCC

Capacity Btu/h 8751± 5 % 10370±5%

Input W 645± 5 % 1125 ±5%

Rated current(RLA) A 2.5 4.3

Locked rotor Amp(LRA) A 16± 10% 21+ 10 %

Thermal protector °F 293±9(Built-in) 293±9(Built-in)

Capacitor uF 15 25

Refrigerant oil ml 190± 10 300± 15

Indoor fan

motor

Model YDK-25-4-1 YDK-25-4-1

Brand Li Feng Li Feng

Insulation class B B

Input W 60 70

Output W 25 25

Rated current A 0.3 0.4

Capacitor uF 2 2

Speed(hi/mi/lo) r/min 1000/850 1150/900

Indoor air ﬂow (Hi/Lo) cfm 390/330 450/340

Indoor Fan Noise Level(265V) dBA 49/45(265v) 52/46(265v)

Indoor Fan Noise Level((265V))cooling mode dBA 52/50(265v) 55/52(265v)

Indoor sound level (sound pressure level) (Fan mode) dB(A)±2 49/45 52/46
