M. TROUBLESHOOTING

M.2 Diagnostic Codes

STATUS LED Indicator Deﬁnitions

INTELLIGENT SELF--CHECKING CONTROL

Your PTAC has a computer board that continuously checks key components of the unit to ensure they are operating properly. Under normal op-

eration, unit status indicator (STATUS,on main PCB), light is steadily ON. If there is a major problem,the unit will shut down and display a diag-

nostic failure code on the unit’s display. If it is only a minor failure and unit is correcting the fault by itself, the diagnostic code will be ﬂashed on

the status LED that can easily be seen when the front panel is removed (see Fig. C.5.2.3). Failure STATUS codes are deﬁned in the table below.

Diagnostic

Code

Description Status Indicator

Indoor ambient temperature sensor is open circuited or short-

circuited.

Dual-8 nixie tube displays“F1” and STATUS indicator will ﬂash once

and off 3s circularly.

F2 Indoor tube temperature sensor is open circuited or short-circuited.

Dual-8 nixie tube displays“F2” and STATUS indicator will ﬂash twice

and off 3s circularly.

Outdoor ambient temperature sensor is open circuited or short-

circuited.

Dual-8 nixie tube displays“F3”.

Outdoor tube temperature sensor is open circuited or short-

circuited.

Dual-8 nixie tube displays“F4” and STATUS indicator will ﬂash four

times and off 3s circularly.

FJ Malfunction of temperature sensor at air outlet. Dual-8 nixie tube displays “FJ”.

Low temperature prevention protection. Dual-8 nixie tube displays “FP”.

Wrong wire connection indication for wired controller. STATUS indicator will ﬂash nine times and off 3s circularly.

High temperature prevention protection for evaporator. STATUS indicator will ﬂash eight times and off 3s circularly.

High temperature prevention protection for outdoor condenser. STATUS indicator will ﬂash six times and off 3s circularly.

Freeze prevention protection for evaporator. STATUS indicator will ﬂash ﬁve times and off 3s circularly.

Frost prevention (heat pump). STATUS indicator will ﬂash seven times and off 3s circularly.

F0 Freon-lacking protection. Dual-8 nixie tube displays “F0”.

H3 Overload detection protection. Dual-8 nixie tube displays “H3”.

E5 Overcurrent protection of compressor. Dual-8 nixie tube displays “E5”.

Malfunction protection for electric heating Relay for Compressor or

heater is broken.

Dual-8 nixie tube displays “A2”.

Unbalanced Electric Current detected between Null line and live

line.

Dual-8 nixie tube displays “U5”.

A0 Electric heater combination wrong. Dual-8 nixie tube displays “A0”.

A4 Electric heater current abnormal. Dual-8 nixie tube displays “A4”.

C7 Temperature limiter protection time too long or fured. Dual-8 nixie tube displays “C7”.

For advanced troubleshooting and repair by

qualiﬁed service technicians:

Scan this QR code to be linked to our professional

support page where you can locate the Service

Manual.
