41 41

WARNING

ELECTRIC SHOCK HAZARD

Disconnect power to the unit before

servicing. Failure to follow this warning

could result in serious injury or death.

Remove the decorative front cover.

1. Using a 1/4” nut driver loosen the four (4) captive screws as shown in ﬁgure 401

Install the decorative front cover.

OPTIONAL: The factory assembles the supply cord so that it exits the left side of the unit at the bottom. At the consumer’s discretion, pull the supply cord taut through the loops (refer

to Cord Routing Change, Section C.6) and route the cord down.

STEP 14. To attach and prevent damage to the front grille, align the cord notch over the cord and center the fresh air lever, then align and tighten the four (4) captive screws as

indicated by the arrows in Figure 401 before closing the front panel, be sure the lter is in place. Make sure curtains do not block the side air intakes.

Figure 401 (Remove and Install the Front Cover)

ROUTINE MAINTENANCE

Remove and Install Front Cover -Kuhl
