Unpacking The Unit

STEP 1 Cut the packing straps and remove box pulling it up, remove corner-post and protective packing, conserve the berboard

wing board in a safe place, it will be used later.

Figure 2

Figure 3

Figure 4

STEP 2 Remove decorative plastic return air grille to a safe area away from the unit.

STEP 3 Remove the installation hardware, two gaskets from beneath the unit, and place them in a safe area away from the unit.

STEP 4 Remove the chassis retainer by removing the far right screw in the basepan (see Figure 4); save this screw to reattach the

chassis retainer after installation.
