Brief introduction
Reversing the door
The side at which the door opens can be
changed from the right side (as supplied) to the
left side, if the installation site requires.
Tools you will need:
1. 8mm socket driver
2. Cross-shaped screwdriver
3. Putty knife or thin-blade screwdriver
Before you start lay the refrigerator on it’s back in
order to gain access to the base, you should rest
it on soft foam packaging or similar material to
avoid damaging the cooling pipes at the rear of
the refrigerator.
13
① screw hole cover ②
③
upper hinge cover
④ upper hinge part
⑤ ⑥
⑦
special flange self-tapping screw
special flange self-tapping screw
adjustable foot
lower hinge parts
1. Open the refrigerator door and remove all the items
on the door;
2. Remove the upper hinge cover (2); Remove two
screws (3); Remove the upper hinge part (4);
3. Take the door up carefully and place the door on the
ground with a soft surface to prevent the surface of the
door from being scratched;
4.
Remove the screw hole cover (1) and transfer it to
the corresponding hole on the right, be sure to firmly
press it into the hole;
5. Remove the two screws (6) at the bottom;
6. Remove the lower hinge parts (5) at the bottom;
7. Remove the left adjustable foot (7) at the bottom,
transfer it to the hole corresponding to the bottom on
the right;
8. Install the previously removed lower hinge parts (5)
into the corresponding hole on the left side of the
bottom, and tighten the screw (6);
9. Install the left hole at the bottom of the door into the
lower hinge parts and close the door;
10. Install the previously removed upper hinge part (4)
to the corresponding hole position on the left side,
screw the screw (3), do not tighten it first, and tighten
the screw when the door is in the horizontal position;
11.
Install the previously removed upper hinge cover
(2) to the corresponding position on the left;
12. The end of changing the door.
