Operation
8. Screw out lower hinge, change it to the
near hole site, and then screw up.
9. Just remount to the step 7, change part
① to left and part ②,⑤ to right and then
fix part ① with screws ④ . Finally install
part ③ .
11. Screw out the upper hinge axis, turn the
upper hinge over and fix axis on it. Then
place it at side for use.
12.
.
13. Move the upper door to appropriate
position, adjust part ① and upper door,
and then fix part ① by screws ② (Please
hold upper door by hand when installing) ,
and then install another part ③ (in the
plastic bag).
Note: When installing part ③, firstly, push it
from left to right completely, then push it
down tight.
10. Move the lower door and adjust its
position to align lower hole site and upper
hinge axis. Turn the middle hinge by 180,
adjust the middle hinge to the appropriate
position and then install it.
1
2
3
4
1
2
3
5
1
2
14. Open the upper door, mount door racks
and then close it.
Remove the screw hole cover ①
,then install it to the right side ② , as
shown in figure below.
12
