PM66MEE22 RANGE COOKERS
COMBI BURNER PLATE
P2 – a rapid electrical burner with a 145 mm diameter;
P1 – a rapid electrical burner with a 180 mm diameter;
A – an auxiliary burner;
R – rapid gas burner.
Figure 10
CONTROL PANEL
Figure 11
A – timer with automatic switch-o ;
B – front left burner knob (for switching on and regulating the power supply);
C – rear left burner knob (for switching on and regulating the power supply);
D – oven thermostat knob;
E – Rear right burner knob (for switching on and regulating the power supply);
F — front right burner knob (for switching on and regulating the power supply);
G – oven mode control knob;
H – power supply indicator (red);
I – oven ignition indicator (amber).
• POWER SUPPLY INDICATOR RED
When the indicator is lit, it means that the oven is in good working order and is
switched on.
• OVEN IGNITION INDICATOR AMBER
When this indicator is switched on, it means that the oven is in the preliminary heating
phase.
• OVEN THERMOSTAT KNOB
The oven thermostat controls the cooking temperature in all settings, including
those for the grill. Turning the corresponding knob clockwise will allow you to set the
temperature inside the oven at the required level within the range of 50°С to 240°С.
• OVEN WORKING MODE KNOB
This switch activates a certain mode needed for cooking. The description of working
modes, as well as tips on how to choose between them, can be found in the chapter
“MULTIFUNCTIONAL ELECTRIC OVEN WITH IN-BUILT FAN”.
• TIMER WITH AUTOMATIC SWITCHOFF
This device allows you to programme the
switch-o time.
Figure 12
• HOW IT WORKS
• Set- the required cooking time (maximum 120 min for an electric cooker,
and 100 min for a gas cooker).
• By turning the thermostat knob, choose the temperature and set the switch
to the required cooking mode sign.
• When the regulating knob reaches the 0 position, the meal is cooked and
the oven will switch o automatically.
• Then turn the thermostat knob to the
position.
• Turn the regulating knob to the
0 position.
NOTE: Without using the programming device, the cooker functions only
when the mode control knob is set to the manual
position.
ATTENTION!
PM66MEE22 range cookers are supplied with an electric multi-functional
oven with an in-built fan and electric grill.
Information on how to use the combined burner plate and the oven can be
found in the subsequent chapters of this manual.
22
PM66MEE22 RANGE COOKERS
АBCD
HI
EFG
