alarm mode is disabled automatically, but only when the temperature of the freezer
compartment falls below -12°C; at this point the ALARM text will no longer be
illuminated, while the temperature will stop ashing and remain lit in a xed manner
on the display.
FREEZER TEMPERATURE ALARM
The alarm function was designed with the aim of warning the user that, due to some
external cause (for example, a power cut, the door has been left open, etc.) the food
kept in the freezer compartment has reached a temperature higher than +1°C and
has therefore completely thawed out.
In this case, the freezer temperature alarm mode is enabled and ashes on the
display, along with the highest temperature detected inside the compartment; the
ALARM text is illuminated in red and the audible alarm is also activated.
The display memory (maximum temperature reached) is important because, if
power is cut o and then restored, the appliance will continue operating as normal;
this could result in food which had previously thawed out being refrozen.
DOOR OPEN ALARM
Every time the door is opened the ( ) symbol (refrigerator) and/or the ( ) symbol
(freezer) lights up in white, in a xed manner; if the door remains open for over 2
minutes, the “Door Open” buzzer alarm sounds; it may be deactivated in one of the
2 following ways:
• by closing the door, both the buzzer and the visible alarm signal deactivate;
• if the (
) symbol (for the refrigerator door) or the ( ) symbol (for the freezer door) is
touched, only the buzzer deactivates, while the white-lit visible alarm signal starts
ashing.
INTERNAL LIGHT
Every time the door is opened, the light inside the refrigerator compartment is
switched on; if the door is opened for an extended period of time, the light switches
o automatically after 5 minutes. To switch it back on, simply close the door and
open it again.
MALFUNCTION MANAGEMENT
If the symbols «E»,»E-»,»-E», appear on the refrigerator-freezer display, the appliance
is guaranteed to function for a few days, but the Technical Assistance Centre should
be contacted immediately.
HOW TO STORE FOOD IN THE REFRIGERATOR
COMPARTMENT
Place the food as shown in the diagram 4.
SPECIAL COMPARTMENT FOR THE PRESERVATION OF MEAT AND
FISH:
Some delicate food stus like meat, sh, and lightly frozen groceries can be placed in a
special box, in which the temperature is kept constant at 0° C.
NOTE:
• The distance between the shelves and the rear internal wall of the refrigerator
ensures that air circulates freely.
• Do not place food in direct contact with the rear wall of the refrigerator
compartment.
• Do not place food that is still warm into the compartments.
• Keep all liquids in closed containers.
• The NO-FROST system guarantees a constant temperature and a more rapid
freezing capacity.
• The humidity-free, forced air circulation tends to dry food up quickly and for
this reason, we advise keeping all food in closed containers.
CAUTION
Whenever the product has been lying horizontally during transportation, it should
be left to stand upright for at least six hours before it is switched on, otherwise it may
be noisy when it is in operation.
Before plugging the appliance in, make sure that the power supply voltage
corresponds to the value shown on the product data plate (“See the section Electrical
connection”).
Plug the appliance into the electricity mains supply. The display will ash, showing
the default temperature set by the manufacturer (7°C for the refrigerator area, -16°C
for the freezer area).
SWITCHING ON THE APPLIANCE
The product is turned on by touching the symbol ( ) for 0.5 seconds, action followed
by an audible signal (1 beep).
It is possible to switch o only the refrigerator compartment by touching the symbol
(
) for 4 seconds (the «--» symbol appears on the display).
The product is turned o by touching the symbol (
) for 5 seconds, followed by an
audible signal (2 beep) and two dash ( ) on the display.
NOTE: in this case, the refrigerator compartment and all the display symbols
are also automatically switched o.
SETTING THE TEMPERATRE OF THE FREEZER AREA
The freezer display indicates the actual internal temperature of the freezer
compartment ranging from +20°C to -40°C; if the temperature exceeds +20°C, the
HOW TO FREEZE FRESH FOOD
The freezer compartment (****) makes it possible to freeze food. The quantity of fresh
food, which can be frozen in 24 hours, is shown on the rating plate (see paragraph
entitled “Electrical wiring”).
Proceed as follows:
• Wrap the food in aluminum foil, transparent lm, plastic waterproof packaging,
covered polyethylene containers, freezer containers.
• Place the groceries in the compartments as indicated in Figure 5; allow
sucient free space around them so that the air can circulate freely.
If there is a power failure, the freezer compartment will keep its preserving
temperature for about 18 hours.
When you purchase frozen food always bear in mind the following factors:
• The packaging or packet must be intact, otherwise the food may spoil. If a packet
is swollen or shows damp marks, it has not been stored in optimum conditions and
may have started to thaw.
• Purchase frozen food goods last and transport them in an insulated box.
• As soon as you arrive home, place the frozen goods immediately in the freezer
compartment.
• Avoid or reduce variations in temperature to a minimum.
• Keep to the expiry date shown on the frozen food package.
• Always follow the instructions on the packaging on how to preserve the frozen
foods.
• The maximum amount of fresh food that can be frozen is shown in kg/24h on the
rating plate with the technical specications.
• Avoid placing food that has to be frozen in contact with food that has already been
frozen so that the latter does not under go a rise in temperature.
PRODUCTION OF ICE CUBES FIG. 5
Fill the ice container three quarters full with water; place it on the appropriate sliding
shelf in the freezer compartment (if available).
DEFROSTING
The fridge-freezer defrosts automatically and therefore there is no need for anything
to be done to it.
WARNING!
Never re-freeze partially thawed food and consume it within 24 hours.
POWER CUT
If a power cut should occur, try to establish its duration.
If the forecast is less than 12 hours, leave the food in the freezer and keep the door
closed.
If the power cut lasts for longer than 12 hours and part of the food starts to thaw out,
this should be consumed as soon as possible.
• Remove the food, wrap it in several layers of newspaper and place it in the fridge
or in a cool location.
• Remember that an increase in the temperature of the food will greatly reduce
its storage life.
WARNING! Do not use any mechanical devices or other articial methods
other that those recommended by the manufacturer for accelerating the
defrosting process.
WARNING! Unless otherwise approved by the manufacturer, do not use
electrical appliances inside the food storage compartment.
CLEANING
WARNING! Before starting any cleaning, disconnect the appliance from
the mains electricity supply.
WARNING! The protections (wire grill, covers) must not be removed by
unqualiedpersonnel: do not use the appliance if the protections have
been removed.
GB
11
STARTING THE APPLIANCE
STARTING THE APPLIANCE USING THE FREEZER COMPARTMENT
