• CHILLER SHELF (In some models)
3 – 4 : For long-term storage of food in the freezer compartment, you can set the knob
to the medium position.
5 : For freezing fresh food. The appliance will work for longer. So, after the desired
condition is reached, return the knob to the previous setting.
WARNINGS ABOUT TEMPERATURE ADJUSTMENTS
• We recommend that you do not operate your fridge in environments where the
ambient temperature is below 10°C because this will reduce its e ciency.
• Temperature adjustments should be made according to the frequency of door
openings and the quantity of food kept inside the fridge.
• Do not pass to another adjustment before completing an adjustment.
• Your fridge should be operated up to 24 hours according to the ambient
temperature without interruption after being plugged in to be completely
cooled. Do not open doors of your fridge frequently and do not place much
food inside it in this period.
• During power cut, to prevent any compressor problem you should unplug the
refrigerator. You should delay pluging in 5 – 10 minutes after your power supply
returns. If you plug out the refrigerator for a reason you should wait at least 5
min to replug. It is important for avoiding damage to refrigerator’s components.
• Your fridge is designed to operate in the ambient temperature intervals stated
in the standards, according to the climate class stated in the information label.
We do not recommend operating your fridge out of stated temperatures value
limits in terms of cooling e ectiveness.
• This appliance is designed for use at an ambient temperature within the 10°C -
43°C range.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
• HUMIDITY CONTROLLER
GB
5
THE VARIOUS FUNCTION AND POSSIBILITIES
THE VARIOUS FUNCTION AND POSSIBILITIES
Climate class Ambient(oC)
T 16 to 43(°C)
ST 16 to 38 (°C)
N 16 to 32 (°C)
ACCESSORIES
• FREEZER BOXES
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
Make the inverse of the same operation for the resetting the sliding compartment.
Note:
Always Keep the handle of box while removing the box.
or
Freezer boxes Freezer boxes
Flap cover
Important!
Do not put foods you want to freeze or ice trays in order to make ice.
When the humidity controler in the
closed position, it allows fresh fruit
and vegetables to be stored longer.
In case of the crisper is totally full,
the fresh dial is located in front
of crisper, should be opened. By
means of this the air in the crisper
and humidity rate will be controlled
and endurance life will be increased.
Keeping food in the Chiller compartment
instead of the freezer or refrigerator
compartment allows food retain freshness
and avour longer, while preserving its fresh
appearance. When chiller tray becomes dirty,
remove it and wash it with water.
(Water freezes at 0°C, but foods containing
salt or sugar freeze at temperature lower
than that)
Normally people use the chiller compartment
for raw sh, lightly pickled, rice, etc...
If you see any condensation on glass shelf, humidity control should be taken into the
open positions.
• ADJUSTABLE DOOR SHELF (In some models)
Six di erent height adjustments can be made to provide storage areas that you need
by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the
shelf and pull the buttons
on the side of the door shelf
direction of arrow (Fig.1).
Position door shelf the
height you need by moving
up and down. After you
get the position that you
want the door shelf, release
the buttons on the side of the door shelf (Fig.2) Before
releasing the door shelf, move up down and make sure
the door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the shelf by
supporting the bottom. Otherwise, door shelf could fall o the rails due to the
weight. So damage may occur on the door shelf or rails.
Visual and text descriptions on the accessories section may vary according to the
model of your appliance.
CLEANING AND MAINTENANCE
Important!
Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp housing and other electrical
components.
• The refrigerator should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water.
• Clean the accessories separately with soap and water Do not clean them in the
dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse with
clean water and dry carefully. When you have nished cleaning, reconnect the
plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help you to save
on energy costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Fig. 1
Fig. 2
