INSTALLATION INSTRUCTIONS AND DOOR REVERSIBILITY
INSTALLATION INSTRUCTIONS
AND DOOR REVERSIBILITY
INSTALLATION INSTRUCTIONS
Important! It is recommended that this installation be performed by
authorized technical stu.
Important!
Before installation, read the instructions carefully.
Important!
Fit the refrigerator/freezer in stable kitchen units only.
Important!
If necessary, reverse the door according to instructions.
1. See g.A for the necessary attachment components.
2. Open the package. Take gasket spacer
9
and brake into three as shown in gure.D.
The middle part is door hang rail
10
. The other two parts are unit door spacers
11
. (g.D)
3. Insert trim ap
1
into slot and screw by screws
6
. (g.E)
4. Pass the power cord through ventilation shaft and position it so that the appliance
could be easily plugged in once it has been installed. (g.B - g.C)
5. Cut trim gasket
4
to the height of the recess and stick it on reverse side of the door
hinges of the appliance. (g.E)
6. Raise the appliance and slide into the kitchen unit.
7. Lean the appliance to the kitchen unit through the hinges and align the front feet
with front surface of the kitchen unit. (g.F)
8. Open the appliance doors and screw the front feet by using screws
7
. (g.G)
9. Screw trim ap
1
to kitchen unit using screws
7
. (g.G)
10. Screw the hinges to the kitchen unit using screws
7
. (g.G)
11. Close the appliance doors. Unscrew and take out the nuts
14
, washers
13
and
adjustment bolts
12
from the appliance upper door
19
. (g.H)
12. Take out the liners of the tapes on door hang rails
10
. Place door hang rails
10
on the
appliance upper door
19
by inserting the bosses on the holes of the appliance upper
door
19
, aligning the front surfaces of the door hang rails
10
and appliance door parallel.
Let the door hang rails
10
stick onto the appliance upper door
19
. (g.H)
13. Slide the door hang
2
into door hang rails
10
. (g.J – g.K)
14. Take out the liners of the tapes on the front side of the door hang
2
.
15. Take out the liners of the tapes on the unit door spacers
11
and and stick them onto
the unit upper door
15
, closer to the upper corners. (g.K)
16. Lean the unit door
15
to the door hang
2
, aligning the unit door spacers
11
on the left,
right and top edges with the sides of the unit or the doors of the nearer and upper
kitchen units. (g.K)
17. Make sure that the unit upper door
15
sticks onto the door hang
2
. Pull the unit door
15
allowing the door hang
2
slide out the door hang rails
10
. Observe that the door hang
2
stays sticked on the unit upper door
15
. (g.L)
18. Lay down the unit upper door
15
to the oor and screw the door hang
2
to the unit
upper door
15
by screws
7
. (g.L)
19. To overcome some of the furniture mistakes, there are plastic spacers
A
sticked on
the door hang
2
. Remove these plastic spacers
A
. (g.M)
20. Remove the door hang rails
10
from the appliance upper door
19
. Screw the
adjustment bolts
12
to the holes on the appliance upper door
19
by leaving the necessary
space using unit door spacer
11
. (g.N)
21. Open the appliance upper door
19
. Place the unit upper door
15
onto the appliance
door inserting adjustment bolts
12
into the slots on the door hang
2
. (g.N)
22. Place the washers
13
and screw the nuts
14
onto the adjustment bolts
12
. (g.N)
23. 1~2 mm gap between the unit itself and unit door is vital for appliance performance.
Close the door and make the accurate adjustment of the unit door
15
by screwing or
unscrewing the adjustment bolts
12
for vertical adjustment and by the help of the slots
on the door hang
2
for other directions. (g.P1)
24. Place the door bottom xings
5
to the bottom of the appliance upper door
19
between the appliance upper door
19
and unit upper door
15
. Screw the door bottom
xings
15
to the appliance door with screws
6
. (g.O)
25. Screw the door bottom xings5 to the unit upper door
15
by screws
7
. (g.O)
26. For the adjustment of the space between the unit upper door
15
and the unit itself,
you can unscrew the screws6 then adjust the space between the appliance upper
door
19
and unit upper door
15
by the spring eect of the door bottom xings
5
while
screwing back the screws
6
.
27. Slide the hang cover
3
onto the door hang
2
. (g.P2)
28. Repeat the same procedure for the lower door.
DOOR REVERSING
Be careful about not to pinch your ngers in the hinges (door upper
hinge
20-a
and door lower hinge
20-b
).
1. Unscrew the screws on the front surface of the appliance upper door
19
. Take the
appliance upper door
19
to safe place. (g.S)
2. Take the hole plugs on the appliance upper door’s
19
front surface, to the holes on the
reverse side. (g.S)
3. Open the door upper hinge
20-a
and door lower hinge
20-b
. (g.S) and dissamble them.
(g.T)
4. Take hole plugs to opposite side. (g.T)
5. Assemble door upper hinge
20-a
and door lower hinge
20-b
to the opposite corner of
their original position. (g.T)
6. Assemble the appliance upper door
19
. (g.U)
7. Repeat the same procedure for the lower door.
