8
INSTRUCTIONS FOR THE INSTALLER
IMPORTANT NOTICE:
THE OPERATIONS INDICATED BELOW MUST BE FOLLOWED BY QUALIFIED PERSONNEL EXCLUSIVELY,
IN CONFORMITY WITH THE REGULATIONS IN FORCE.
THE MANUFACTURING FIRM REFUSES ALL RESPONSIBILITY FOR DAMAGES TO PEOPLE, ANIMALS OR
THINGS, RESULTING FROM THE FAILURE TO COMPLY WITH SUCH PROVISIONS.
INSTALLATION
Attention!
The installation must be performed in conformity with current regulations.
• INSTALLING THE TOP
The appliance is designed to be embedded into heat-resistant pieces of furniture.
The walls of the pieces of furniture must resist a temperature of 75°C besides the room one.
The equipment must not be installed near inammable materials, such as curtains, cloths, etc. Make a hole in the top
of the piece of furniture, with the dimensions indicated in g. 3, at a distance of at least 50 mm from the appliance
border to the adjacent walls.
(*) Necessary size for the installation with cover.
Any possible wall unit over the cook-top must be placed at a
distance of at least 760 mm from the top.
It is advisable to isolate the appliance from the piece of furniture below with a separator, leaving a depression space
of at least 10 mm (g. 4).
If the hob is going to be installed on the top of an oven, precautions must be taken to guarantee an installation in
accordance with current accident prevention standards. Pay particular attention to the position of the electric cable
and gas pipe: they must not touch any hot parts of the oven.
Moreover, if the hob is going to be installed on the top of a built in oven without forced cooling ventilation, proper
air vents must be installed to guarantee an adequate ventilation, with the lower air entering with a cross section of at
least 200cm
2
, and the higher air exiting with a cross section of at least 60cm
2
.
• FASTENING THE TOP
Every cook-top is equipped with a special washer. A set of hooks is also supplied for mounting the cook-top.
Depending on the type of mounting surface, the suitable type of mounting hook is supplied (hook A or hook B).
For the installation proceed as follows:
• Remove the racks and burners from the top.
• Turn the appliance upside down and lay the washer S along the external border (g. 5).
• Introduce and place the cook-top in the hole made in the piece of furniture, then block it with the V screws
of the fastening hooks G (g.6).
• INSTALLATION ROOM
This appliance is not provided with a device for exhausting the products of combustion.
Regarding room ventilation rules where appliance is installed make reference to the legislation, in conformity with
the local regulations.
The room where the appliance is installed must have a minimum volume of 20m
3
.
ATTENTION:
The electrical connection of the cooking hob and the oven must be carried out separately for security
issues and to allow easy removal of the oven from the unit.
MODEL L (mm) P (mm)
HP640VGT 560 480
INSTRUCTIONS FOR THE INSTALLER
