CLEANING AND MAINTENANCE
!
WARNING
• Do not use steam cleaning equipment.
• Before cleaning, make sure the cooking zones are switched o and that the residual heat indicator (“H“) is not displayed.
Important:
• Do not use abrasive sponges or scouring pads as they may damage
the glass.
• After each use, clean the hob (when it is cool) to remove any deposits
and stains from food residue.
• A surface that is not kept suitably clean may reduce the sensitivity of
control panel buttons.
• Use a scraper only if residues are stuck to the hob. Follow the scraper
manufacturer's instructions to avoid scratching the glass.
• Sugar or foods with a high sugar content can damage the hob and
must be immediately removed.
• Salt, sugar, and sand could scratch the glass surface.
• Use a soft cloth, absorbent kitchen paper, or a special hob cleaner
(follow the Manufacturer’s instructions).
• Spills of liquid in the cooking zones can cause the pots to move or vibrate.
• After cleaning the hob, dry thoroughly.
TROUBLESHOOTING
• Check that the electricity supply has not been shut o.
• If you are unable to turn the hob o after using it, disconnect it from the
power supply.
• If alphanumeric codes appear on the display when the hob is switched on,
consult the following table for instructions.
Please note: The presence of water, liquid spilled from pots or any objects
resting on any of the hob buttons can accidentally activate or deactivate
the control panel lock function.
DISPLAY CODE DESCRIPTION POSSIBLE CAUSES SOLUTION
F0E1
Cookware is detected, but it is not
compatible with the requested
operation.
The cookware is not well positioned on
the cooking zone or is not compatible
with one or more cooking zones.
Press On/O button twice to remove the
F0E1 code and restore the cooking zone's
functionality. Then, try to use the cookware
with a dierent cooking zone, or use
dierent cookware.
F0E7
Wrong power cord connection. The power supply connection is not
exactly as indicated in the “ELECTRICAL
CONNECTION“ paragraph.
Adjust the power supply connection
according to “ELECTRICAL CONNECTION“
paragraph
.
F0EA
The control panel switches o because
of excessively high temperatures.
The internal temperature of the
electronic parts is too high.
Wait for the hob to cool down before using
it again.
F0E9
The cooking zone turns o when the
temperatures are too high.
The internal temperature of electronic
parts is too high.
Wait until the cooking area has cooled o
before using it again.
F0E2, F0E4, F0E6,
F0E8, F0EC, F1E1,
F2E1, F6E1, F6E3,
F7E5, F7E6
Disconnect the hob from the power supply.
Wait a few seconds then reconnect the hob to the power supply.
If the problem persists, call the service centre and specify the error code that appears on the display.
d E
[when the hob is off]
The hob does not switch heat up.
The functions do not come on.
DEMO MODE on.
Follow the instructions in the “DEMO
MODE“ paragraph.
e.g.
:
The hob does not allow a special
function to be activated.
The power regulator limits the power
levels in accordance with the maximum
value set for the hob.
See paragraph “Power management“.
e.g.
[
Power level lower than
level requested
]
The hob automatically sets a minimum
power level to ensure that the cooking
zone can be used.
The power regulator limits the power
levels in accordance with the maximum
value set for the hob.
See paragraph “Power management“.
– 12 –
