T2
Short Turns the motor on/off at the second speed. Fixed
Long press with
light or motor on
24h Function
Activates/Deactivates the motor in the 24h Air Exchange mode, a
speed that allows suction of 10 minutes every hour, for a 24-hour
cycle.
Cannot be activated if the Intensive or Delay modes are active.
Flashing
Long press with
all loads off (mo-
tor and lights)
Wi-Fi connection
Activates/Deactivates the Wi-Fi Connection function.
Note: the Wi-Fi function is automatically activated when the user re-
quests the Wi-Fi configuration procedure.
LED S1 Flashing:
connection to domestic
network in progress.
LED S1 Fixed: Wi-Fi
connection activated.
T3
Short Turns the motor on at the third speed. Fixed
Long press with
light or motor on
Turns the motor on at the Intensive 1 speed.
This speed is timed for 10 minutes. At the end of this time, the system
automatically returns to the previously selected speed. If activated
with the motor off, once the time has passed it switches to OFF mode.
Flashing
By pressing the key again with a long press (with light or motor on),
the motor starts at the Intensive 2 speed.
This speed is timed for 6 minutes. At the end of this time, the system
automatically returns to the previously selected speed. If activated
with the motor off, once the time has passed it switches to OFF mode.
Fast flashing
Long press with
all loads off (mo-
tor and lights)
The Filter saturation alarm is reset.
All LEDs flash 3 times.
Signals the saturated Metal Grease Filters alarm and the need to
wash them. The alarm is activated after 100 hours of effective hood
operation.
LEDs T2 and T3 lit with
the hood off.
Signals the Activated Charcoal Odour Filter saturation alarm. The
alarm is activated after 200 hours of effective hood operation.
LEDs T2 and T3 flash-
ing with the hood off.
T4
Short
AUTO Mode
Activates/Deactivates the Automatic operating mode.
AUTO mode is deactivated whenever any other keys are pressed.
AUTO mode is activated when the key is pressed or the Coupled In-
duction Cooktop is turned on. The hood speed is automatically set
using the highest power level present on the hob. When the induction
cooktop is turned off the last activated speed is held for 5 seconds,
then speed 1 for 15 minutes. Once the 15 minutes have passed the
motor turns off. The light status does not change.
Fixed on: AUTO mode
activated.
Off: AUTO mode tem-
porarily deactivated.
Long press with
light on and mo-
tor off
Induction/Gas Cooktop Selection
Select the type of cooktop in use, either Induction or Gas.
The Induction Cooktop is set by default.
1 Flash: confirms the In-
duction Cooktop selec-
tion.
2 Flashes: confirms the
Gas Cooktop selection.
Long press with
all loads off (mo-
tor and lights)
Wi-Fi configuration
Activates/Deactivates the Wi-Fi set-up procedure.
Before starting the procedure, use the Franke@Home App to re-
gister with the Franke IOT system. Then follow the instructions to add
a new device and register the domestic router.
If the procedure is not successfully completed within a few minutes,
deactivate it by long pressing the key again, then make another at-
tempt. The hood will nonetheless abandon the procedure if it is not
successfully completed within 15 minutes.
LEDs T3 and T4 flash-
ing: configuration pro-
cedure in progress.
Upon successful com-
pletion of the procedure
LEDs T3 and T4 will
light up for 2 seconds.
Recommended device coupling sequence:
1 - K-Link Mode (See “connected mode” of remote control manual)
2 - K-Link Coupling (See hood manual)
3 - Remote Control-Hood Coupling (See remote control manual)
4 - K-Link Coupling (See hood manual)
5 - Cooktop-Hood Coupling (See induction cooktop manual)
5. FRANKE@HOME APP
The Franke@Home App is available for
iOS and Android smartphones and al-
lows remote access to all hood func-
tions.
13
