Burner Minimum Maximum
Wok burner
Rapid burner
Other burner
N/A
100mm
100mm
315mm
270mm
195mm
-21- -22-
Operation instructions
1. Please make sure the diameter of the pan used is equal to or more than cook area
2. To avoid rubbing the surface,using clean and bottom-slick pan
3. To get best cooking results, the bottom of porcelain enamel steel pan shall be 2-3mm
thick, the bottom of stainless steel filled pan shall be 4-6mm thick
Please choose the proper Pan before cooking Do not use griddle:
■ Cookware size limitation
1. Do not try to use an oversize pan with the wok attachment as damage and injury could occur.
Only use a wok on the wok attachment.
2. Do not try to remove the Rapid grate until the cooking grates and cooktop surface have
completely cooled down.
■ Rapid Grate
Operation instructions
(1) Press the "+" or "-" button of the left burner briefly to activate the timer function, and then the
nixie tube on the left will flash, indicating the remaining of time for the left burner.
(2) Touch the button to adjust the time to 00 minutes.
(3) The corresponding nixie tube goes out in 3 seconds and the timer will be canceled.
Switching the timer off before time (with the left burner as the example)
When the timer counts down to the last 1 minute, the cooktop will buzz once and the nixie tube
will switch to a 60-second countdown. When it counts down to 0, the cooktop buzzes 5 times and
then the burner flame goes out. After the cooktop is ignited, it works for 4 continuous hours at
most, and then the flame will be turned off automatically for protection. After the control knob is
reset, ignite again and a new cycle begins.
Time lapsed
In case of a power failure during normal operation, the nixie tube will indicate "E1" after the
power restores as the control knob is not reset. Reset the control knob to eliminate the "E1", and
the cooktop will function normally.
Power failure indication
(1) Press the "+" or "-" button of the left burner briefly to activate the timer function, and then the
nixie tube on the left will flash, indicating the remaining of time for the left burner.
(2) Touch the "+" or "-" button of the left burner to adjust the time.
(3) After the adjustment is done, the timer starts in 3 seconds. The nixie tube indicates the timer
set and keeps being on.
Changing the timer (with the left burner as the example)
Setting the timer (with the left burner as the example)
(1) Keep pressing the "+" or "-" button of the left burner to activate the timer function, and then
the nixie tube on the left will flash. The default time is 15 minutes.
(2) Touch the "+" or "-" button of the left burner to adjust the time.
(3) After the adjustment is done, the timer starts in 3 seconds. The nixie tube indicates the timer
set and keeps being on.
Note: The timer of the left and the middle burners may be set either separately or simultane-
ously.
Description of the buttons
Keep pressing the timing plus button to activate the timer function. When the function is
activated (the nixie tube is flashing), touch this button to increase the time for 1 minute.
Keep pressing the button to increase the time continuously, up to 180 minutes.
Keep pressing the timing minus button to activate the timer function. When the function is
activated (the nixie tube is flashing), touch this button to decrease the time for 1 minute.
Keep pressing the button to decrease the time continuously, down to 0 minute.
The 3-digit timing nixie tubes indicate the time of the left and the middle/front right burners
respectively.
GLG90305&GLG90305-Y
Timing digital tube(L)
Timing digital tube(C)
Left timing
minus button
Left timing
plus button
Middle timing
minus button
Middle timing
plus button
GLG90505&GLG60305&GLG60305-Y
Timing digital tube(L) Timing digital tube(RF)
Left timing
minus button
Left timing
plus button
RF timing
minus button
RF timing
plus button
